12.15.2. Digital output 1
Settings for digital output 1.
Parameter
Name / value range / [default setting]
Info
0x2634:002
(P420.02)
Digital outputs function: Digital output 1
(Dig.out.function: DO1 function)
For further possible settings, see parameter
0x2634:001 (P420.01).  429
Assignment of a trigger to digital output 1.
Trigger = FALSE: X3/DO1 set to LOW level.
Trigger = TRUE: X3/DO1 set to HIGH level.
Notes:
An inversion set in 0x2635:002 (P421.02)
is taken into consideration
here.
115
Release holding brake
Trigger signal for releasing the holding brake (TRUE = release holding
brake).
Note!
If this trigger is assigned to the relay or a digital output, the deceleration
times set for the respective output are not effective (are internally set to
"0"). Only the deceleration time set in 0x2820:012 (P712.12) for closing
the holding brake influences in this case the time-dependent behaviour
of the output.
 Holding brake control

302
0x2635:002
(P421.02)
Inversion of digital outputs: Digital output 1
(DO inversion: DO1 inversion)
Inversion of digital output 1
0
Not inverted
1
Inverted
0x4016:003
Digital output 1: Cutout delay
0.000 ... [0.000] ... 65.535 s
Switch-off delay for digital output 1.
Note!
The set delay time is not effective (internally set to "0") if the relay is
assigned to the trigger "Release holding brake [115]". Only the
deceleration time set in 0x2820:012 (P712.12)
for closing the holding
brake influences the time-dependent behaviour of the digital output.
0x4016:004
Digital output 1: Switch-on delay
0.000 ... [0.000] ... 65.535 s
Switch-on delay for digital output 1.
Note!
The set delay time is not effective (internally set to "0") if the relay is
assigned to the trigger "Release holding brake [115]". Only the
deceleration time set in 0x2820:012 (P712.12)
for closing the holding
brake influences the time-dependent behaviour of the digital output.
0x4016:005 Digital output 1: Terminal state
Read only
Display of the logic state of output terminal X3/DO1.
0
FALSE
1
TRUE
0x4016:006 Digital output 1: Trigger signal state
Read only
Display of the logic state
of the trigger signal for digital output 1 (without
taking a ON/OFF delay set and inversion into consideration).
0
FALSE
1
TRUE
12.15.3. NetWordOUT1 status word
Assignment of digital triggers to bit 0 ... bit 15 of the NetWordOUT1 status word.
Details
The following table shows the preset status assignment of the NetWordOUT1 data word:
Bit
Default setting
For details and configuration, see
0
Ready for operation
0x2634:010 (P420.10)
1 Not connected 0x2634:011 (P420.11)
2
Operation enabled
0x2634:012 (P420.12)
3
Error active
0x2634:013 (P420.13)
4
Not connected
0x2634:014 (P420.14)
5
Quick stop active
0x2634:015 (P420.15)
6 Running 0x2634:016 (P420.16)
7
Device warning active
0x2634:017 (P420.17)
