8.5.2. CANopen node address
Each network node must be provided with a unique node address.
Details
• • The node address can be set in 0x2301:001 (P510.01).
• • The setting that is active when the inverter is switched on is the effective setting.
• • The active node address is shown in 0x2302:001 (P511.01).
Parameter
Name / value range / [default setting]
Info
0x2301:001
(P510.01)
CANopen settings: Node ID
(CANopen sett.: Node ID)
1 ... [1] ... 127
Setting of the node address.
A change in the node address will not be effective until a CAN Reset
Node is performed.
0x2302:001
(P511.01)
Active CANopen settings: Active node ID
(CANopen diag.: Active node ID)
Read only
Display of the active node address.
0x2303
(P509.00)
CANopen switch position
(CANopen switch)
Read only
Display of the DIP switch setting at the last mains power-on.
8.5.3. CANopen baud rate
All network nodes must be set to the same baud rate.
Details
• • The baud rate can be set in 0x2301:002 (P510.02).
• • The setting that is active when the inverter is switched on is the effective setting.
• • The active baud rate is displayed in 0x2302:002 (P511.02).
Parameter
Name / value range / [default setting]
Info
0x2301:002
(P510.02)
CANopen settings: Baud rate
(CANopen sett.: Baud rate)
Setting of the baud rate.
A change in the baud rate will not be effective until a CAN reset node
is
performed.
0
Automatic
(from version 03.00)
1 20 kbps Setting of the baud rate.
A change in the baud rate will not be effective until a CAN reset node
is
performed.
2
50 kbps
3
125 kbps
4
250 kbps
5
500 kbps
6 800 kbps
7
1 Mbps
0x2302:002
(P511.02)
Active CANopen settings: Active baud rate
(CANopen diag.: Active baud rate)
Read only
Display of the active baud rate.
0 Automatic (from version 03.00)
1
20 kbps
2
50 kbps
3
125 kbps
4
250 kbps
5 500 kbps
6
800 kbps
7
1 Mbps
