Emotron VS10 User Manual

7.4.2. Inverter Characteristics
The inverter characteristic is automatically set if one of the following optimisations is
carried out:
 Automatic motor identification (energized)  139
 Automatic motor calibration (non-energized)  140
The settings made can be seen if required, but should not be changed. A
wrong setting may influence the control negatively!
Parameter
Name / value range / [default setting]
Info
0x2947:001 Inverter characteristic: Value y1
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
The inverter characteristic (consisting of 17 values) is calculated and set
during the automatic identification of the motor data. If only an
automatic calibration of the motor data is carried out, a default inverter
characteristic is loaded instead.
Note!
Changing these values is not recommended by the manufacturer.
0x2947:002
Inverter characteristic: Value y2
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:003
Inverter characteristic: Value y3
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:004
Inverter characteristic: Value y4
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:005
Inverter characteristic: Value y5
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:006 Inverter characteristic: Value y6
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:007
Inverter characteristic: Value y7
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:008
Inverter characteristic: Value y8
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:009
Inverter characteristic: Value y9
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:010
Inverter characteristic: Value y10
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:011
Inverter characteristic: Value y11
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:012
Inverter characteristic: Value y12
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:013
Inverter characteristic: Value y13
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:014
Inverter characteristic: Value y14
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:015 Inverter characteristic: Value y15
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:016
Inverter characteristic: Value y16
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
0x2947:017
Inverter characteristic: Value y17
0.00 ... [0.00]* ... 20.00 V
* Default setting depending on the size.
