Emotron VS10 - 3-Phase Mains Connection 480 V; Rated Data

468 01-6203-01R3, CG Drives & Automation
13.5. 3-phase mains connection 480 V
13.5.1. Rated data
The output currents apply to these operating conditions:
• At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
• At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter
VS30-40-1P3 VS30-40-1P8 VS30-40-2P4 VS30-40-3P2 VS30-40-3P9 VS30-40-5P6
Rated power kW
0.37 0.55 0.75 1.1 1.5 2.2
Mains voltage range
3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Rated mains current
without mains choke
A
1.5
2.1
2.8
3.7
4.5
6.5
with mains choke
A
1.2
1.7
2.2
2.5
3.1
4.4
Apparent output power kVA 0.9 1.2 1.6 2.2 2.6 3.6
Output current
2 kHz
A
-
1.6
2.1
3
3.5
4.8
4 kHz
A
1.1
1.6
2.1
3
3.5
4.8
8 kHz
A
1.1
1.6
2.1
3
3.5
4.8
16 kHz A 0.7 1.1 1.4 2 2.3 3.2
Power loss
4 kHz
W
20
25
32
40
48
66
8 kHz
W
24
31
40
51
61
85
at controller inhibit
W
6
6
6
6
6
6
Overcurrent cycle 180 s
Max. output current
A
1.7
2.4
3.2
4.5
5.3
7.2
Overload time
s
60
60
60
60
60
60
Recovery time
s
120
120
120
120
120
120
Max. output current during the
recovery time
A
0.8 1.2 1.6 2.3 2.6 3.6
Overcurrent cycle 15 s
Max. output current
A
2.2
3.2
4.2
6
7
9.6
Overload time
s
3
3
3
3
3
3
Recovery time
s
12
12
12
12
12
12
Max. output current during the
recovery time
A
0.8 1.2 1.6 2.3 2.6 3.6
Cyclic mains switching
3 times per minute
Max. motor cable length shielded
without EMC category m 15 50
Category C2
m
15
20
Weight
kg
0.75
0.95
1.35
