Emotron VS10 User Manual

462 01-6203-01R3, CG Drives & Automation
13. Technical data
13.1. Standards and operating conditions
13.1.1. Protection of persons and device protection
Degree of protection
IP20
EN 60529
Type 1 NEMA 250 Protection against contact
Open type
only in UL-approved systems
Insulation resistance
Overvoltage category III
EN 61800-5-1
0 … 2000 m a.m.s.l.
Overvoltage category II
above 2000 m a.m.s.l.
Control circuit isolation
Safe mains isolation by double/reinforced
insulation
EN 61800-5-1
Protective measures against
Short circuit
earth fault
Earth fault strength depends on the operating status
overvoltage
Motor stalling
Motor overtemperature
I²xt monitoring
Leakage current
> 3.5 mA AC, > 10 mA DC
EN 61800-5-1
Observe regulations and safety instructions!
Starting current
≤ 3 x rated mains current
13.1.2. EMC data
Actuation on public supply systems
Implement measures to limit the radio
interference to be expected:
The machine or plant manufacturer is responsible for compliance
with the requirements for the machine/plant!
< 1 kW: with mains choke
EN 61000-3-2
> 1 kW at mains current ≤ 16 A: without
additional measures
Mains current > 16 A: with mains choke or
mains filter, with dimensioning for rated
power. Rsce ≥ 120 is to be met.
EN 61000-3-12
RSCE: short-circuit power ratio at the connection point of the
machine/plant to the public network.
Noise emission
Category C2 EN 61800-3 Type-dependent, for motor cable lengths see rated data
Noise immunity
Meets requirement in compliance with
EN 61800-3
13.1.3. Motor connection
Requirements to the shielded motor cable
Capacitance per unit length
C-core-core/C-core-shield < 75/150 pF/m
≤ 2.5 mm² / AWG 14
C-core-core/C-core-shield < 150/300 pF/m ≥ 4 mm² / AWG 12
Electric strength
Uo/U = 0.6/1.0 kV
U = r.m.s. value external conductor/external conductor
U ≥ 600 V
UL
