7.7.6. Motor torque monitoring
This function monitors the motor torque during operation.
Preconditions
The motor torque monitoring can only be used for the following motor control types with
speed controller:
• Sensorless control (SL PSM)
• Sensorless vector control (SLVC)
Details
This function sets the internal status signal "Torque limit reached [79]" = TRUE if the
maximum possible torque has been reached.
• The status signal is set irrespective of the response 0x2D67:001 (P329.01) and delay
time 0x2D67:002 (P329.02) set for this monitoring.
•
The user can use the status signal to activate certain functions.  Flexible I/O
configura- tion
 357
• The status signal also serves to set a digital output or a bit of the NetWordOUT1 status
word.
 Configuration of digital outputs  429
Parameter
Name / value range / [default setting]
Info
0x2D67:001
(P329.01)
Maximum torque monitoring: Response
(MaxTrq.Monitor: Response)
From version 02.00
For further possible settings, see parameter
0x2D45:001 (P310.01).  163
Selection of response to reaching the maximum possible torque.
The selected response takes place if the status signal "Torque limit
reached [79]" = TRUE and the deceleration time set in 0x2D67:002
(P329.02) has elapsed.
Associated error code:
33553 | 0x8311 Torque limit reached
0
No response
 Error types  84
0x2D67:002
(P329.02)
Maximum torque monitoring: Triggering delay
(MaxTrq.Monitor: Triggering delay)
0.000 ... [0.000] ... 10.000 s
From version 02.00
Optional setting of a deceleration for triggering the response selected in
0x2D67:001 (P329.01).
Typical application:
The motor should be driven at the torque limit for a short time with
out
triggering the selected response.
Only after a longer operation (> set deceleration) at the torque limit,
the selected response is to take place.
0x6072
(P326.00)
Max torque
(Max torque)
0.0 ... [250.0] ... 3000.0 %
From version 02.00
Symmetrical selection of the maximum permissible torque.
100 % ≡ Motor rated torque 0x6076 (P325.00)
This parameter serves to implement a statically and bipolarly acting
torque limitation. This can be used, for instance, as overload
protection of the mechanical transmission path/elements starting
at the motor shaft.
This limitation acts irrespective of the torque limitations acting in
uni
polar mode that are set in 0x60E0 and 0x60E1.
0x60E0
Positive torque limit
0.0 ... [250.0] ... 3276.7 %
From version 02.00
Positive torque limit source for speed control with torque limitation.
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x60E1
Negative torque limit
0.0 ... [250.0] ... 3276.7 %
From version 02.00
Negative torque limit source for speed control with torque limitation.
100 % ≡ Motor rated torque 0x6076 (P325.00)
