8.2.3. Further process data
The parameters listed in the following can also be mapped to network registers, in order
to transmit control and status information as well as setpoints and actual values as
process data.
Details
• The following parameters are always available irrespective of the network option.
• The use of these parameters for the transmission of process data is optional. It is also
possible to only use a part of the parameters. For the transmission of the frequency
setpoint and actual value, for instance, several parameters with a different resolution
can be selected.
• Via the parameters, at the same time the general network activity can be diagnosed.
NetWordIN1 ... NetWordIN4
These four mappable data words are provided to individually control the inverter:
Data word
Parameter
Intended use
NetWordIN1
0x4008:001 (P590.01)
For implementing an individual control word format.
 General network settings

167
NetWordIN2 0x4008:002 (P590.02) For controlling the digital outputs via network.
 Configuration of digital outputs

429
NetWordIN3
0x4008:003 (P590.03)
For controlling the analog outputs via network.
 Configuration of analog outputs  437
NetWordIN4 0x4008:004 (P590.04)
