Emotron VS10 - Page 208

208 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x4008:003
(P590.03)
Process input words: NetWordIN3
(NetWordINx: NetWordIN3)
0.0 ... [0.0] ... 100.0 %
Mappable data word for optional control of an analog output via net-
work.
Assignment of the analog output:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN3 [20]"
0x4008:004
(P590.04)
Process input words: NetWordIN4
(NetWordINx: NetWordIN4)
0.0 ... [0.0] ... 100.0 %
Mappable data word for optional control of an analog output via net-
work.
Assignment of the analog output:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN4 [21]"
0x400A:001
(P591.01)
Process output words: NetWordOUT1
(NetWordOUTx: NetWordOUT1)
Read only
Mappable data word for the output of status messages of the inverter
via network.
Bit 0 Mapping bit 0 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:010 (P420.10)
Bit 1
Mapping bit 1
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:011 (P420.11)
Bit 2
Mapping bit 2
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:012 (P420.12)
Bit 3
Mapping bit 3
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:013 (P420.13)
Bit 4
Mapping bit 4
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:014 (P420.14)
Bit 5 Mapping bit 5 Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:015 (P420.15)
Bit 6
Mapping bit 6
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:016 (P420.16)
Bit 7
Mapping bit 7
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:017 (P420.17)
Bit 8
Mapping bit 8
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:018 (P420.18)
Bit 9
Mapping bit 9
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:019 (P420.19)
Bit 10
Mapping bit 10
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:020 (P420.20)
Bit 11
Mapping bit 11
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:021 (P420.21)
Bit 12
Mapping bit 12
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:022 (P420.22)
Bit 13
Mapping bit 13
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:023 (P420.23)
Bit 14
Mapping bit 14
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:024 (P420.24)
Bit 15
Mapping bit 15
Mappable data word for the output of status messages of the inverter
via network.
Assignment of the status message: 0x2634:025 (P420.25)
