Emotron VS10 - Page 207

NetWordOUT1 and NetWordOUT2
These two mappable data words are provided to output status messages to the network
master:
Data word
Parameter
Intended use
NetWordOUT1
0x400A:001 (P591.01)
For implementing an individual status word format.
 NetWordOUT1 status word

433
NetWordOUT2
0x400A:002 (P591.02)
For the output of messages of the "sequencer" function.
 Segment configuration

329
The following describes all further process data.
Parameter
Name / value range / [default setting]
Info
0x4008:001
(P590.01)
Process input words: NetWordIN1
(NetWordINx: NetWordIN1)
0x0000 ... [0x0000] ... 0xFFFF
Mappable data word for flexible control of the inverter via network.
Bit 0
Mapping bit 0
Assignment of the function: 0x400E:001 (P505.01)
Bit 1
Mapping bit 1
Assignment of the function: 0x400E:002 (P505.02)
Bit 2
Mapping bit 2
Assignment of the function: 0x400E:003 (P505.03)
Bit 3
Mapping bit 3
Assignment of the function: 0x400E:004 (P505.04)
Bit 4
Mapping bit 4
Assignment of the function: 0x400E:005 (P505.05)
Bit 5
Mapping bit 5
Assignment of the function: 0x400E:006 (P505.06)
Bit 6
Mapping bit 6
Assignment of the function: 0x400E:007 (P505.07)
Bit 7
Mapping bit 7
Assignment of the function: 0x400E:008 (P505.08)
Bit 8
Mapping bit 8
Assignment of the function: 0x400E:009 (P505.09)
Bit 9
Mapping bit 9
Assignment of the function: 0x400E:010 (P505.10)
Bit 10
Mapping bit 10
Assignment of the function: 0x400E:011 (P505.11)
Bit 11
Mapping bit 11
Assignment of the function: 0x400E:012 (P505.12)
Bit 12
Mapping bit 12
Assignment of the function: 0x400E:013 (P505.13)
Bit 13
Mapping bit 13
Assignment of the function: 0x400E:014 (P505.14)
Bit 14 Mapping bit 14 Assignment of the function: 0x400E:015 (P505.15)
Bit 15
Mapping bit 15
Assignment of the function: 0x400E:016 (P505.16)
x4008:002
(P590.02)
Process input words: NetWordIN2 Mappable data word for optional control of the digital outputs via net-
work.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selection [34] ... [49]
•
Digital output 1: 0x2634:002 (P420.02) / selection [34] ... [49]
(NetWordINx: NetWordIN2)
0x0000 ... [0x0000] ... 0xFFFF
Bit
0
Mapping bit 0
Bit 1 Mapping bit 1
Bit 2
Mapping bit 2
Bit 3
Mapping bit 3
Bit 4
Mapping bit 4
Bit 5
Mapping bit 5
Bit 6
Mapping bit 6
Bit 7
Mapping bit 7
Bit 8
Mapping bit 8
Bit 9
Mapping bit 9
Bit 10 Mapping bit 10
Bit 11
Mapping bit 11
Bit 12 Mapping bit 12
Bit 13
Mapping bit 13
Bit 14
Mapping bit 14
Bit 15
Mapping bit 15
