Emotron VS10 - Page 189

Parameter
Name / value range / [default setting]
Info
48
Activate PID influence ramp
Trigger bit = 1: the influence of the process controller is shown by
means of a ramp.
Trigger bit = 0 or not connected: the influence of the process controller
is shown by means of a ramp.
Notes:
The influence of the process controller is always active (not only when
PID control is activated).
Acceleration time for showing the influence of the process controller
can be set in 0x404C:001 (P607.01).
Deceleration time for hiding the influence of the process controller
can be set in 0x404C:002 (P607.02).
 Configuring the process controller

232
49
Release holding brake
Trigger bit = 1: Release holding brake manually.
Trigger bit = 0: No action.
Notes:
The manually triggered "Release holding brake" command has a direct
impact on the "Release holding brake [115]" trigger.
Thus, the holding
brake can be manually released if the power section is switched off.
The responsibility for a manual release of the holding brake has the
external trigger source for the "Release holding brake" command.
 Holding brake control

302
50 Select sequence (bit 0) Selection bits for bit coded selection of a sequence.
Notes:
The selected sequence is not started automatically.
For a status-controlled start, the function "Run/abort sequence [30]"
is
available.
 Sequencer control functions

416
51
Select sequence (bit 1)
52
Select sequence (bit 2)
53
Select sequence (bit 3)
54
Position counter reset
Trigger bit = 1: Reset position counter manually.
Trigger bit = 0: No action.
 Position counter

320
0x400E:002
(P505.02)
NetWordIN1 function: Bit 1
(NetWordIN1 fct.: NetWordIN1.01)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).  168
Definition of the function that is to be triggered via bit 1 of the
mappable NetWordIN1 data word.
0
Not active
Trigger bit without any function.
0x400E:003
(P505.03)
NetWordIN1 function: Bit 2
(NetWordIN1 fct.: NetWordIN1.02)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).

168
Definition of the function that is to be triggered via bit 2 of the
mappable NetWordIN1 data word.
3
Activate quick stop
Trigger bit = 1: "Quick stop" function activated.
Trigger bit = 0: no action / deactivate function again.
Notes:
The "Quick stop" function brings the motor to a standstill within the
deceleration time set in 0x291C (P225.00).
The "Quick stop" function has a higher priority than the "Run"
func
tion.
0x400E:004
(P505.04)
NetWordIN1 function: Bit 3
(NetWordIN1 fct.: NetWordIN1.03)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).  168
Definition of the function that is to be triggered via bit 3 of the
mappable NetWordIN1 data word.
0
Not active
Trigger bit without any function.
