Parameter
Name / value range / [default setting]
Info
0x400E:005
(P505.05)
NetWordIN1 function: Bit 4
(NetWordIN1 fct.: NetWordIN1.04)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).

168
Definition of the function that is to be triggered via bit 4 of the
mappable NetWordIN1 data word.
8
Run forward (CW)
Trigger bit = 0-1 edge: Motor is started in forward rotating direction
(CW).
Trigger bit = 1-0 edge: Motor is stopped again.
Notes:
The stop method can be selected in 0x2838:003 (P203.03).
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
The function also serves to realise an automatic start after switch-on.
 Starting performance  97
The "Invert rotation [13]" function can be used in connection with this
function.
0x400E:006
(P505.06)
NetWordIN1 function: Bit 5
(NetWordIN1 fct.: NetWordIN1.05)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).

168
Definition of the function that is to be triggered via bit 5 of the
mappable NetWordIN1 data word.
18
Activate preset (bit 0)
Selection bits for bit coded selection and activation of a parameterised
setpoint (preset).
 Setpoint source of preset setpoints

386
0x400E:007
(P505.07)
NetWordIN1 function: Bit 6
(NetWordIN1 fct.: NetWordIN1.06)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).  168
Definition of the function that is to be triggered via bit 6 of the
mappable NetWordIN1 data word.
19
Activate preset (bit 1)
Selection bits for bit coded selection and activation of a parameterised
setpoint (preset).
 Setpoint source of preset setpoints

386
0x400E:008
(P505.08)
NetWordIN1 function: Bit 7
(NetWordIN1 fct.: NetWordIN1.07)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).

168
Definition of the function that is to be triggered via bit 7 of the
mappable NetWordIN1 data word.
4
Reset error
Trigger bit = 0-1 edge: Active error is reset (acknowledged) if the error
condition is not active anymore and the error is resettable.
Trigger bit = 0: No action.
Notes:
After resetting the error, a new enable/start command is required to
restart the motor.
 Error handling

84
0x400E:009
(P505.09)
NetWordIN1 function: Bit 8
(NetWordIN1 fct.: NetWordIN1.08)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x400E:001 (P505.01).

168
Definition of the function that is to be triggered via bit 8 of the
mappable NetWordIN1 data word.
0
Not active
Trigger bit without any function.
