12.13. Configuration of digital inputs
Settings for digital inputs 1 ... 5.
Parameter
Name / value range / [default setting]
Info
0x2630:002
(P410.02)
Settings for digital inputs: Input function
(DI settings: Input function)
Input function of the digital terminals DI3 and DI4.
0
Digital input
DI3 = digital input
DI4 = digital input
0x2632:001
(P411.01)
Inversion of digital inputs: Digital input 1
(DI inversion: DI1 inversion)
Inversion of digital input 1
0
Not inverted
1
Inverted
0x2632:002
(P411.02)
Inversion of digital inputs: Digital input 2
(DI inversion: DI2 inversion)
Inversion of digital input 2
0
Not inverted
1
Inverted
0x2632:003
(P411.03)
Inversion of digital inputs: Digital input 3
(DI inversion: DI3 inversion)
Inversion of digital input 3
0
Not inverted
1
Inverted
0x2632:004
(P411.04)
Inversion of digital inputs: Digital input 4
(DI inversion: DI4 inversion)
Inversion of digital input 4
0
Not inverted
1 Inverted
0x2632:005
(P411.05)
Inversion of digital inputs: Digital input 5
(DI inversion: DI5 inversion)
Inversion of digital input 5
0
Not inverted
1
Inverted
0x2633:001
Digital input debounce time: Digital input 1
1 ... [1] ... 50 ms
Debounce time of digital input 1
0x2633:002
Digital input debounce time: Digital input 2
1 ... [1] ... 50 ms
Debounce time of digital input 2
0x2633:003
Digital input debounce time: Digital input 3
1 ... [1] ... 50 ms
Debounce time of digital input 3
0x2633:004 Digital input debounce time: Digital input 4
1 ... [1] ... 50 ms
Debounce time of digital input 4
0x2633:005
Digital input debounce time: Digital input 5
1 ... [1] ... 50 ms
Debounce time of digital input 5
Example: Activating two functions simultaneously via digital input 4
The principle of assigning triggers to functions also enables a digital input to be assigned
to several functions. The wiring complexity is reduced since there is no necessity to
interconnect several digital inputs.
If, for instance, the frequency preset 1 is to be selected via the digital input 4 and a
changeover to the acceleration time 2 and deceleration time 2 is to take place at the same
time, this can be easily realised by the following parameter setting:
Parameter
Name
Setting for this example
0x2631:018 (P400.18) Activate preset (bit 0) Digital input 4 [14]
0x2631:039 (P400.39)
Activate ramp 2
Digital input 4 [14]
In order to achieve the desired behaviour, the digital input 4 must not be
assigned to any further functions!
