Emotron VS10 - Fusing and Terminal Data

18 01-6203-01R3, CG Drives & Automation
3.2.1.2. Fusing and terminal data
Fuse data
Inverter
VS10-23-1P7 VS10-23-2P4 VS10-23-3P2 VS10-23-4P2 VS10-23-6P0 VS10-23-7P0 VS10-023-9P6
Cable installation in compliance with
EN 60204-1
Laying system
B2
operation without mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current
A
10
10
16
16
25
25
25
Circuit breaker
Characteristics B
Max. rated current
A
10
10
16
16
25
25
25
operation
with mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current A 10 10 16 16 25 25 25
Circuit breaker
Characteristics
B
Max. rated current
A
10
10
16
16
25
25
25
Earth-leakage circuit breaker
1-phase mains connection ≥ 30 mA, type A or B
Mains connection
Inverter
VS10-23-1P7 VS10-23-2P4 VS10-23-3P2 VS10-23-4P2 VS10-23-6P0 VS10-23-7P0 VS10-023-9P6
Connection
X100
Connection type pluggable screw terminal
Min. cable cross-section
mm²
1
Max. cable cross-section
mm²
2.5
6
Stripping length
mm
8
Tightening torque
Nm
0.5
0.7
Required tool 0.5 x 3.0 0.6 x 3.5
Connection
PE
Connection type
PE screw
Min. cable cross-section
mm²
1
Max. cable cross-section
mm²
6
Stripping length mm 10
Tightening torque
Nm
1.2
Required tool
0.8 x 5.5
