Emotron VS10 - Customer Specific Configurations

Parameter
Name / value range / [default setting]
Info
0x400C:001
(P593.01)
Process output data: AC Drive status word
(Process data OUT: AC status word)
Read only
Mappable status word with bit assignment in compliance with
EtherNet/IP™ AC drive profile.
Bit 0 Fault/Trip active
Bit 1
Warning active
Bit 2
Running forward
Bit 3 Running reverse
Bit 4
Ready
Bit 5
Network control active
Bit 6
Network setpoint active
Bit 7
At Reference
Bit 8
Profile-State bit 0
The drive status is coded as follows:
0: Manufacturer-specific (reserved)
1: Startup (Drive initialisation)
2: Not_Ready (Mains voltage switched off)
3: Ready (Mains voltage switched on)
4: Enabled (Drive has received run command)
5: Stopping (Drive has received stop command and is stopped)
6: Fault_Stop (Drive is stopped due to a fault)
7: Faulted (Faults have occurred)
Bit 9
Profile-State bit 1
Bit 10 Profile-State bit 2
Bit 11
Profile-State bit 3
Bit 12
Process controller active
Bit 13 Torque mode active
Bit 14
Current limit reached
Bit 15
DC braking active
0x6402
Motor type
From version 02.00
AC motor type
Motor Data Object (0x28) instance attribute 3
3
PM synchronous
6
Wound rotor induction
7
Squirrel cage induction
8.2.2.1. Customer specific configurations
The Emotron VS10/30 inverter does not support any customer-specific configurations.
