12.3.7. Setpoint source segment setpoints
The four functions "Activate segment setpoint (bit 0)" ... " Activate segment setpoint´(bit
3)" enable a setpoint change-over to a segment setpoint parameterised for the
"sequencer" function during normal operation.
Preconditions
A setpoint change-over to the respective segment setpoint is only effected if no setpoint
source with a higher priority has been selected.
Priority of the setpoint sources
380
Details
A segment setpoint is selected in a binary-coded fashion via the triggers assigned to the
four functions "Activate segment setpoint (bit 0)" ... " Activate segment setpoint´(bit 3)" in
compliance with the following truth table:
Activate segment setpoint
Selection
Bit 3
0x2631:029
(P400.29)
Bit 2
0x2631:028
(P400.28)
Bit 1
0x2631:027
(P400.27)
Bit 0
0x2631:026
(P400.26)
Segment
Frequency setpoint
PID setpoint
Torque setpoint
FALSE
FALSE
FALSE
FALSE
No segment setpoint selected
FALSE
FALSE
FALSE
TRUE
1
0x4026:001 (P801.01)
0x4026:006 (P801.06)
0x4026:007 (P801.07)
FALSE
FALSE
TRUE
FALSE
2
0x4027:001 (P802.01)
0x4027:006 (P802.06)
0x4027:007 (P802.07)
FALSE
FALSE
TRUE
TRUE
3
0x4028:001 (P803.01)
0x4028:006 (P803.06)
0x4028:007 (P803.07)
FALSE
TRUE
FALSE
FALSE
4
0x4029:001 (P804.01)
0x4029:006 (P804.06)
0x4029:007 (P804.07)
FALSE
TRUE
FALSE
TRUE
5
0x402A:001 (P805.01)
0x402A:006 (P805.06)
0x402A:007 (P805.07)
FALSE
TRUE
TRUE
FALSE
6
0x402B:001 (P806.01)
0x402B:006 (P806.06)
0x402B:007 (P806.07)
FALSE
TRUE
TRUE
TRUE
7
0x402C:001 (P807.01)
0x402C:006 (P807.06)
0x402C:007 (P807.07)
TRUE
FALSE
FALSE
FALSE
8
0x402D:001 (P808.01)
0x402D:006 (P808.06)
0x402D:007 (P808.07)
TRUE
FALSE
FALSE
TRUE
Invalid selection
...
TRUE
TRUE
TRUE
TRUE
