Emotron VS10 - Stopping the Deceleration Ramp Function Generator

284 01-6203-01R3, CG Drives & Automation
0x2541:001
(P706.01)
Brake energy management: Operating mode
(Brake management: Operating mode)
Selection of the braking method.
The braking method(s) selected is/are activated if the DC-bus voltage
exceeds the voltage threshold for the braking operation shown in
0x2541:002 (P706.02).
1
Ramp function generator stop (RFGS)
The deceleration ramp function generator is stopped.
 Stopping the deceleration ramp function generator

268
3
Inverter motor brake (IMB) + RFGS
Braking with the "Inverter motor brake" braking method in connection
with "Deceleration ramp function generator stop" is executed.
 Inverter motor brake

269
0x2541:002
(P706.02)
Brake energy management: Active threshold
(Brake management: Active threshold)
Read only: x V
Display of the active voltage threshold for the braking operation.
The voltage threshold shown depends on the mains voltage selected
in
0x2540:001 (P208.01) and the voltage value set in 0x2541:003
(P706.03).
The voltage threshold must be higher than the stationary DC voltage
in
the DC bus.
0x2541:003
(P706.03)
Brake energy management: Reduced threshold
(Brake management: Red. threshold)
0 ... [0] ... 100 V
The voltage threshold for the braking operation is reduced by the
voltage value set here.
0x2541:005
(P706.05)
Brake energy management: Deceleration override
time
(Brake management: Del.overr.time)
0.0 ... [2.0] ... 60.0 s
Maximum permissible time for the deceleration override by means of
the braking method selected in 0x2541:001 (P706.01).
If the DC-bus voltage does not fall below the voltage threshold for
braking operation shown in 0x2541:002 (P706.02) within this time,
the motor is decelerated further.
The time is only reset if the voltage threshold shown in 0x2541:002
(P706.02) is not reached.
0x2540:001
(P208.01)
Mains settings: Rated mains voltage
(Mains settings: Mains voltage)
Setting can only be changed if the inverter is
inhibi
ted.
Selection of the mains voltage for actuating the inverter.
0
230 Veff
1
400 Veff
2
480 Veff
10.5.1. Stopping the deceleration ramp function generator
The deceleration ramp function generator is stopped for a short time if the voltage
threshold for braking operation is exceeded.
Details
When this braking method is selected, the maximum permissible time for the deceleration
override has to be set in 0x2541:005 (P706.05).
• If the DC-bus voltage does not fall below the voltage threshold for braking operation
shown in 0x2541:002 (P706.02) within this time, the motor is decelerated further.
• The time is only reset if the voltage threshold shown in 0x2541:002 (P706.02) is not
reached.
