5.2.7. Setpoint diagnostic
The following parameters show the current setpoints of different setpoint sources.
Parameter
Name / value range / [default setting]
Info
0x282B:007 Inverter diagnostics: Default frequency setpoint
• Read only: x.x Hz
•
From version 03.00
Display of the frequency setpoint of the standard setpoint source set
in 0x2860:001 (P201.01).
0x282B:008 Inverter diagnostics: Preset frequency setpoint
• Read only: x.x Hz
•
From version 03.00
Display of the preset frequency setpoint selected via the four
functions "Activate preset (bit 0)" ... " Activate preset (bit 3)".
 Setpoint source of preset setpoints

386
0x282B:009
Inverter diagnostics: Actual frequency setpoint
• Read only: x.x Hz
•
From version 03.00
Display of the currently selected frequency setpoint that is internally
transferred to the motor control.
0x282B:010
Inverter diagnostics: Default PID setpoint
• Read only: x.xx PID unit
•
From version 03.00
Display of the PID control value of the standard setpoint source set in
0x2860:002 (P201.02).
0x282B:011
Inverter diagnostics: Preset PID setpoint
• Read only: x.xx PID unit
•
From version 03.00
Display of the preset PID setpoint selected via the four functions
"Activate preset (bit 0)" ... " Activate preset (bit 3)".
 Setpoint source of preset setpoints

386
0x282B:012 Inverter diagnostics: Default torque setpoint
• Read only: x.x %
•
From version 03.00
Display of the torque setpoint of the standard setpoint source set in
0x2860:003 (P201.03).
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x282B:013
Inverter diagnostics: Preset torque setpoint
• Read only: x.x %
•
From version 03.00
Display of the preset torque setpoint selected via the four functions
"Activate preset (bit 0)" ... " Activate preset (bit 3)".
 Setpoint source of preset setpoints

386
0x2948:001
Actual torque setpoint
• Read only: x.x %
•
From version 03.00
Display of the currently selected torque setpoint that is internally
transferred to the motor control.
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x2DAE:010
Sequencer diagnostics: Frequency setpoint
• Read only: x.x Hz
•
From version 03.00
Display of the current frequency setpoint of the "sequencer" function.
 Sequencer  327
0x2DAE:011
Sequencer diagnostics: PID setpoint
• Read only: x.xx PID unit
•
From version 03.00
Display of the current PID control value of the "sequencer" function.
 Sequencer  327
0x2DAE:012
Sequencer diagnostics: Torque setpoint
• Read only: x.x %
•
From version 03.00
Display of the current torque setpoint of the "sequencer" function.
• 100 % ≡ Motor rated torque 0x6076 (P325.00)
 Sequencer

327
0x4009:004
MOP values saved: Frequency setpoint
•
Read only: x.x Hz
Display of the last MOP value saved internally for the operating mode
"MS: Velocity mode".
0x4009:005
MOP values saved: PID setpoint
•
Read only: x.xx PID unit
Display of the last MOP value saved internally for the reference value
of the PID control.
0x4009:006 MOP values saved: Torque setpoint
•
Read only: x.x %
Display of the last MOP value saved internally for the operating mode
"MS: Torque mode".
Related topics
 Selection of setpoint source  93
 Setpoint change-over  378
