6. Basic setting
This chapter contains the most frequently used functions and settings to adapt the
inverter to a simple application based on the default setting.
• Mains voltage  90
• Control source selection  92
• Selection of setpoint source  93
• Starting/stopping performance  97
• Frequency limits and ramp times  100
• Quick stop  103
• S-shaped ramps  105
• Optical device identification  106
6.1. Mains voltage
The rated mains voltage set for the inverter has an impact on the operating range of the
inverter.
Details
By default, the rated mains voltage in 0x2540:001 (P208.01) is set according to the
product code of the inverter.
Check the setting of the rated mains voltage in 0x2540:001 (P208.01). Ensure that it
matches the actual mains voltage applied!
Region
inverter
Product code
0x2000:001 (P190.01)
Rated mains voltage
Default setting
Possible settings
EU VS10, 230 V, 1-phase VS10-23-xxx-20 230 Veff [0] 230 Veff [0]
us
VS10, 230 V, 1-phase
VS10-23-xxx-20
230 Veff [0]
230 Veff [0]
EU
VS30, 230 V, 1/3-phase
VS30-23-xxx-20
230 Veff [0]
230 Veff [0]
US
VS30, 230 V, 1/3-phase
VS30-23-xxx-20
230 Veff [0]
230 Veff [0]
EU
VS30, 400 V, 3-phase
VS30-40-xxx-20
400 Veff [1]
400 Veff [1], 480 Veff [2]
US VS30, 480 V, 3-phase VS30-40-xxx-20 480 Veff [2] 400 Veff [1], 480 Veff [2]
Notes regarding the table:
• The inverter types 400/480 V can be used with different mains voltages. For setting the
internal limit values, the rated mains voltage can be set in 0x2540:001 (P208.01) by the
user.
• If the inverter is reset to the delivery status, the rated mains voltage is also reset to the
default setting listed in the table according to the product code.
The following results from the rated mains voltage set:
• the error threshold for monitoring the DC-bus voltage and
• the voltage threshold for braking operation ("brake chopper threshold").
