7.3.6. Synchronous motor: Pole position identification (PPI)
If a permanent-magnet synchronous motor is operated at the inverter, the inverter can be
configured in such a way that a "pole position identification (PLI)" is executed after every
inverter enable.
Preconditions
In 0x2C00 (P300.00) the motor control type "Sensorless control (SL PSM) [3]" is selected.
Details
The pole position is the angle between the motor phase U and the field axis of the rotor.
The "Pole position identification (PPI) without movement" function is available for the
inverter
VS10/30 for identifying the pole position. For details see the following
subchapters.
 162
If an error occurs during the pole position identification,
• the procedure is stopped without the settings being changed.
• the response set in 0x2C60 is effected.
Parameter
Name / value range / [default setting]
Info
0x2C60
PPI monitoring: Reaction
• From version 04.00
•
For further possible settings, see parameter
0x2D45:001 (P310.01)
.

194
Selection of the response triggered by the occurrence of an error during
the pole position identification (PLI).
Associated error code:
• 28961
|
0x7121
Pole position identification fault
3
Fault

Error types  111
