14.3. Parameter attribute list
The parameter attribute list in particular contains some information required for reading
and writing parameters via network.
• The parameter attribute list contains all parameters of the inverter.
• The parameter attribute list is sorted by addresses (index:subindex) in ascending order.
How to read the parameter attribute list:
Column
Meaning
Address
Address of the parameter in the object directory. Format: index:subindex
If the parameter can also be accessed via keypad, the "Display Code" is given in addition in brackets.
Name
Parameter name
Default setting Default setting of the parameter
Category
Functional assignment of the parameter, for example "motor control" or "CANopen".
Data type
Data type of the parameter:
I8
1 byte, with sign
I16
2 bytes with sign
I32 4 bytes with sign
I64
8 bytes with sign
U8
1 byte without sign
U16
2 bytes without sign
U32
4 bytes without sign
U64 8 bytes without sign
REAL32
4 bytes floating point
STRING[xx]
ASCII string (with character length xx)
OCTET[xx]
OCTET string (with xx bytes)
IDX
4 bytes without sign. Is used specially for addressing parameters.
Factor Factor for data transmission via network, depending on the number of decimal positions:
1
No decimal positions
10
1 decimal position
100
2 decimal positions
1000
3 decimal positions
10000 4 decimal positions
A
Attributes (combinations of several attributes also possible):
C
Setting can only be changed if the inverter is inhibited.
E
Value is displayed as IP address on the keypad.
H
Value is displayed as hexadecimal value on the keypad.
I Parameter is not displayed.
K
Parameter is only displayed on the keypad.
O
Parameter can be recorded with the oscilloscope function.
P
Setting is saved in the memory module.
X
Parameter is not displayed in the engineering tools.
M Mapping:
r
Receive mapping permissible.
t
Transmit mapping permissible.
rt
Receive and transmit mapping permissible.
-
Mapping not permissible.
