8.5.11. CANopen diagnostic counter
The following parameters serve to diagnose the communication activities between the
inverter and the CANopen network. The counters are free-running, i. e. when the
maximum value has been reached, the respective counter starts at 0 again.
Parameter Name / value range / [default setting] Info
0x230A:000
CANopen statistics: Highest subindex
Read only
Number of frame and error counters.
0x230A:001
(P580.01)
CANopen statistics: PDO1 received
(CAN statistics: PDO1 received)
Read only
Display of the number of PDO1 telegrams received.
0x230A:002
(P580.02)
CANopen statistics: PDO2 received
(CAN statistics: PDO2 received)
Read only
Display of the number of PDO2 telegrams received.
0x230A:003
(P580.03)
CANopen statistics: PDO3 received
(CAN statistics: PDO3 received)
Read only
Display of the number of PDO3 telegrams received.
0x230A:005
(P580.05)
CANopen statistics: PDO1 transmitted
(CAN statistics: PDO1 transmitted)
Read only
Display of the number of PDO1 telegrams sent.
0x230A:006
(P580.06)
CANopen statistics: PDO2 transmitted
(CAN statistics: PDO2 transmitted)
Read only
Display of the number of PDO2 telegrams sent.
0x230A:007
(P580.07)
CANopen statistics: PDO3 transmitted
(CAN statistics: PDO3 transmitted)
Read only
Display of the number of PDO3 telegrams sent.
0x230A:009
(P580.09)
CANopen statistics: SDO1 telegrams
(CAN statistics: SDO1 counter)
Read only
Display of the number of SDO1 telegrams.
0x230A:010
(P580.10)
CANopen statistics: SDO2 telegrams
(CAN statistics: SDO2 counter)
Read only
Display of the number of SDO2 telegrams.
0x230B
(P518.00)
CANopen error counter
(CAN errorcounter)
Read only
Display of the total number of CAN faults that have occurred.
