12.15. Configuration of digital outputs
Parameter
Name / value range / [default setting]
Info
0x404D:003
(P608.03)
PID alarms: Monitoring bandwidth PID feedback
signal
(PID alarms: Bandw. feedback)
0.00 ... [2.00] ... 100.00 %
From version 04.00
Hysteresis for status signal "PID feedback = setpoint [73]".
100 % ≡ configured variable input range
Example: Variable input range 0 ... 10 V: 2 % ≡ 0.2 V
The status signal "PID feedback = setpoint [73]" is TRUE if the control
led
variable fed back = process controller setpoint (± hysteresis set here).
The status signal can be assigned to the relay, a digital output of the
NetWordOUT1 status word.
 Configuration of digital outputs 
428
12.15.1. Relay
Settings for the relay.
Relay is not suitable for direct switching of a electromechanical holding
brake!
Use a corresponding suppressor circuit in case of an inductive or capacitive
load!
Parameter
Name / value range / [default setting]
Info
0x2634:001
(P420.01)
Digital outputs function: Relay
(Dig.out.function: Relay function)
Assignment of a trigger to the relay.
Trigger = FALSE: X9/NO-COM open and NC-COM closed.
Trigger = TRUE: X9/NO-COM closed and NC-COM open.
Notes:
An inversion set in 0x2635:001 (P421.01)
is taken into consideration
here.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
1 Constant TRUE Trigger is constantly TRUE.
11
Digital input 1
State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideration.
12
Digital input 2
State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideration.
13
Digital input 3
State of X3/DI3, taking an inversion set in 0x2632:003 (P411.03) into
consideration.
14
Digital input 4
State of X3/DI4, taking an inversion set in 0x2632:004 (P411.04) into
consideration.
15
Digital input 5
State of X3/DI5, taking an inversion set in 0x2632:005 (P411.05) into
consideration.
30
NetWordIN1 bit 12
State of NetWordIN1/bit 12 ... 15.
Display of NetWordIN1 in 0x4008:001 (P590.01).
For implementing an individual control word format, NetWordIN1 can
be mapped to a process data input word.
31
NetWordIN1 bit 13
32
NetWordIN1 bit 14
33
NetWordIN1 bit 15
34
NetWordIN2 bit 0
State of NetWordIN2/bit 0 ... bit 15.
Display of NetWordIN2 in 0x4008:002 (P590.02).
For controlling the digital outputs via network, NetWordIN2 can be
mapped to a process data input word.
35
NetWordIN2 bit 1
36
NetWordIN2 bit 2
37
NetWordIN2 bit 3
38
NetWordIN2 bit 4
39
NetWordIN2 bit 5
40
NetWordIN2 bit 6
41
NetWordIN2 bit 7
42
NetWordIN2 bit 8
43
NetWordIN2 bit 9
44
NetWordIN2 bit 10
45
NetWordIN2 bit 11
46
NetWordIN2 bit 12
