Emotron VS10 - Fusing and Terminal Data

28 01-6203-01R3, CG Drives & Automation
3.2.4.2. Fusing and terminal data
Fuse data
Inverter
VS30-40-1P3 VS30-40-1P8 VS30-40-2P4 VS30-40-3P2 VS30-40-3P9 VS30-40-5P6
Cable installation in compliance with
EN 60204-1
Laying system
B2
operation without mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current
A
10
10
10
16
16
16
Circuit breaker
Characteristics B
Max. rated current
A
10
10
10
16
16
16
operation
with mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current A 10 10 10 16 16 16
Circuit breaker
Characteristics
B
Max. rated current
A
10
10
10
16
16
16
Earth-leakage circuit breaker
3-phase mains connection ≥ 30 mA, type B
Fuse data
Inverter
VS30-40-7P3
VS30-40-9P5
VS30-40-013
VS30-40-016
Cable installation in compliance with
EN 60204-1
Laying system
B2
operation
without mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current A 25 25 25 32
Circuit breaker
Characteristics
B
Max. rated current
A
25
25
25
32
operation
with mains choke
Fuse
Characteristics
gG/gL or gRL
Max. rated current A 25 25 25 32
Circuit breaker
Characteristics
B
Max. rated current A 25 25 25 32
Earth-leakage circuit breaker
3-phase mains connection
≥ 30 mA, type B
