12.7. Activating ramp 2 manually
The "Activate ramp 2" function serves to manually activate acceleration time 2 and
deceleration time 2.
Parameter
Name / value range / [default setting]
Info
0x2631:039
(P400.39)
Function list: Activate ramp 2
(Function list: Activ. ramp 2)
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate ramp 2" function.
Trigger = TRUE: activate acceleration time 2 and deceleration time 2
manually.
Trigger = FALSE: no action / deactivate function again.
Notes:
If the function is used and the assigned trigger = TRUE, the auto
change-over threshold 0x291B (P224.00) for ramp 2 is deactivated.
Acceleration time 2 can be set in 0x2919 (P222.00).
Deceleration time 2 can be set in 0x291A (P223.00).
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2917
(P220.00)
Acceleration time 1
(Accelerat.time 1)
0.0 ... [5.0] ... 3600.0 s
Acceleration time 1 for the operating mode "MS: Velocity mode".
The acceleration time set refers to the acceleration from standstill to
the maximum frequency set. In the case of a lower setpoint selection,
the actual acceleration time is reduced accordingly.
Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]".
 Device profile CiA 402

299
0x2918
(P221.00)
Deceleration time 1
(Decelerat.time 1)
0.0 ... [5.0] ... 3600.0 s
Deceleration time 1 for the operating mode "MS: Velocity mode".
The deceleration time set refers to the deceleration from the
maxi
mum frequency set to standstill. In the case of a lower actual
frequency, the actual deceleration time is reduced accordingly.
Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]".
 Device profile CiA 402

299
0x2919
(P222.00)
Acceleration time 2
(Accelerat.time 2)
0.0 ... [5.0] ... 3600.0 s
Acceleration time 2 for the operating mode "MS: Velocity mode".
The acceleration time set refers to the acceleration from standstill to
the maximum frequency set. In the case of a lower setpoint selection,
the actual acceleration time is reduced accordingly.
The acceleration time 2 is active if the frequency setpoint (absolute
value) ≥ auto switching threshold 0x291B (P224.00) or the trigger
assigned to the function "Activate ramp 2" in 0x2631:039 (P400.39) =
TRUE.
The acceleration time 2 is also used for changing the MOP setpoint
generated by the "motor potentiometer" function.
Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]".
 Device profile CiA 402  299
0x291A
(P223.00)
Deceleration time 2
(Decelerat.time 2)
0.0 ... [5.0] ... 3600.0 s
Deceleration time 2 for the operating mode "MS: Velocity mode".
The deceleration time set refers to the deceleration from the
maxi
mum frequency set to standstill. In the case of a lower actual
frequency, the actual deceleration time is reduced accordingly.
The deceleration time 2 is active if the frequency setpoint (absolute
value) ≥ auto change-over threshold 0x291B (P224.00) or the trigger
assigned to the function "Activate ramp 2" in 0x2631:039 (P400.39) =
TRUE.
The deceleration time 2 is also used for changing the MOP setpoint
generated by the "motor potentiometer" function.
Setting is not effective in the operating mode 0x6060 (P301.00) =
"CiA: Velocity mode [2]".
 Device profile CiA 402  299
