5.2. Diagnostics parameter
The inverter provides many diagnostic parameters which are helpful for operation,
maintenance, error diagnosis, error correction, etc.
• In the following overview the most common diagnostic parameters are listed. For the
keypad you can find these diagnostic parameters in group 1.
• Further parameters for more specific diagnostic purposes are described in the following
subchapters.
• The diagnostic parameters can only be read and cannot be written to.
Parameter
Name / value range / [default setting]
Info
0x2030 CRC parameter set
•
Read only
Display of the 32-bit hash sum for the integrity check of the parameter
set.
0x2B0B
Frequency setpoint
• Read only: x.x Hz
•
From version 03.00
Display of the actual frequency setpoint that is internally transferred
to the motor control (after scaling and ramp generator).
0x2B0E
(P102.00)
Frequency setpoint
(Freq. setpoint)
•
Read only: x.x Hz
Display of the frequency setpoint currently assigned.
•
Depending on the present operating conditions, this value may
differ
from the current output frequency 0x2DDD (P100.00).
0x2B0F
VFC output frequency
•
Read only: x.x Hz
Display of the current output frequency at V/f operation.
0x2D4F
(P123.00)
Motor utilisation (i²*t)
(Mot. i2t utilis.)
•
Read only: x %
Display of the current thermal motor utilisation.
0x2D87
(P105.00)
DC-bus voltage
(DC-bus voltage)
•
Read only: x V
Display of the current DC-bus voltage.
0x2D88
(P104.00)
Motor current
(Motor current)
•
Read only: x.x A
Display des present current-r.m.s. value.
0x2D89
(P106.00)
Motor voltage
(Motor voltage)
•
Read only: x VAC
Display of the current motor voltage.
0x2DA2:001
(P108.01)
Output power: Effective power
(Output power: Effective power)
•
Read only: x.xxx kW
Display of the active output power for an energy analysis in the
respective application.
0x2DA2:002
(P108.02)
Output power: Apparent power
(Output power: Apparent power)
•
Read only: x.xxx kVA
Display of the apparent output power for an energy analysis in the
respective application.
0x2DA3:001
(P109.01)
Output energy: Motor
(Output energy: Motor)
•
Read only: x.xx kWh
Display of the output power in motor mode for an energy analysis in
the respective application.
0x2DA3:002
(P109.02)
Output energy: Generator
(Output energy: Generator)
•
Read only: x.xx kWh
Display of the output power in generator mode for an energy analysis
in the respective application.
0x2DDD
(P100.00)
Output frequency
(Output frequency)
•
Read only: x.x Hz
Display of the current output frequency for diagnostics of the control.
0x400D
(P101.00)
Scaled actual value
(Scaled act value)
•
Read only: x Units
Display of the current speed in application units.
0x6077
(P107.00)
Torque actual value
(Torque actual)
•
Read only: x.x %
Display of the current torque.
•
100 % ≡ Motor rated torque 0x6076 (P325.00)
0x6078
(P103.00)
Current actual value
(Current actual)
•
Read only: x.x %
Display of the present motor current.
•
100 % ≡ Motor rated current 0x6075 (P323.00)
