Emotron VS10 - Page 414

414 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2631:026
(P400.26)
Function list: Activate segment setpoint (bit 0)
(Function list: Setp: Segment b0)
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate segment setpoint (bit 0)"
function.
Selection bit with the valency 20 for the bit-coded selection and
activation of a parameterised segment setpoint.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
During normal operation (no active sequence), this function serves to
activate the setpoint of a segment (instead of an entire sequence in
the sequencer operation).
This function is not intended for the use in the sequencer operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:027
(P400.27)
Function list: Activate segment setpoint (bit 1)
(Function list: Setp: Segment b1)
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate segment setpoint (bit 1)"
function.
Selection bit with the valency 2
1
for the bit-coded selection and
activation of a parameterised segment setpoint.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
During normal operation (no active sequence), this function serves to
activate the setpoint of a segment (instead of an entire sequence in
the sequencer operation).
This function is not intended for the use in the sequencer operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:028
(P400.28)
Function list: Activate segment setpoint (bit 2)
(Function list: Setp: Segment b2)
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate segment setpoint (bit 2)"
function.
Selection bit with the valency 2
2
for the bit coded selection and
activation of a parameterised segment setpoint.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
During normal operation (no active sequence), this function serves to
activate the setpoint of a segment (instead of an entire sequence in
the sequencer operation).
This function is not intended for the use in the sequencer operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:029
(P400.29)
Function list: Activate segment setpoint´(bit 3)
(Function list: Setp: Segment b3)
From version 03.00
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate segment setpoint´(bit 3)"
function.
Selection bit with the valency 2
3
for the bit coded selection and
activation of a parameterised segment setpoint.
Trigger = FALSE: selection bit = "0".
Trigger = TRUE: selection bit = "1".
Notes:
During normal operation (no active sequence), this function serves to
activate the setpoint of a segment (instead of an entire sequence in
the sequencer operation).
This function is not intended for the use in the sequencer operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
