Emotron VS10 - Page 351

Parameter
Name / value range / [default setting]
Info
0x4029:009
Sequencer segment 4: Position setpoint
0 ... [0] ... 4294967295
From version 03.00
0x402A:001
(P805.01)
Sequencer segment 5: Frequency setpoint
(Segment 5: Frequency setp.)
-599.0 ... [0.0] ... 599.0 Hz
From version 03.00
Frequency setpoint for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
Direction of rotation according to sign.
0x402A:002
(P805.02)
Sequencer segment 5: Acceleration/deceleration
(Segment 5: Accel./decel.)
0.0 ... [5.0] ... 3600.0 s
From version 03.00
Acceleration/deceleration for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
The set time refers to the acceleration from standstill to the set
maxi
mum frequency. The deceleration is effected with the same
ramp.
0x402A:003
Sequencer segment 5: Time
Runtime for the segment after the expiry of which it is switched over to
the next step of the sequence.
Only relevant for Sequencer mode 0x4025 (P800.00) = "Time
opera
tion [1]" or "Time & step operation [3]".
With the setting "0.0", the segment will be skipped.
(P805.03)
(Segment 5: Time)
0.0 ... [0.0] ... 100000.0 s
From version 03.00
0x402A:004 Sequencer segment 5: Digital outputs Optionally: Set digital outputs to the level set here for the execution
(P805.04)
(Segment 5: Digital outp.)
time of the segment.
0 ... [0] ... 255
From version 03.00
Note!
In order that the control of a digital output is executed by the
sequencer,
the following assignment must be made for the respective digital out-
put:
Relay: 0x2634:001 (P420.01) = "Sequencer controlled [100]"
Digital output 1: 0x2634:002 (P420.02) = "Sequencer controlled [100]"
Bit 0 Relay 0 = X9/NO-COM open and NC-COM closed.
1 = X9/NO-COM closed and NC-COM open.
An inversion set in 0x2635:001 (P421.01)
is taken into consideration
here.
Bit 1
Digital output 1
0 = set digital output 1 to LOW level.
1 = set digital output 1 to HIGH level.
An inversion set in 0x2635:002 (P421.02) is taken into consideration
here.
Bit 2
Digital output 2
Not availabl e for inverter Emotron VS10/30.
0x402A:005 Sequencer segment 5: Analog outputs Optionally: Set analog output to the voltage value set here for the
execu-
(P805.05)
(Segment 5: Analog outp.)
tion time of the segment.
0.00 ... [0.00] ... 10.00 VDC
From version 03.00
Note!
In order that the control of the analog output is executed by the
sequencer, the following assignment must be made for the analog out-
put:
Analog output 1: 0x2639:002 (P440.02) = "Sequencer controlled [10]"
0x402A:006
Sequencer segment 5: PID setpoint
PID control value for the segment.
(P805.06)
(Segment 5: PID setp.)
Only relevant if the PID control in 0x4020:001 (P600.01) is activated.
-300.00 ... [0.00] ... 300.00 PID unit
From version 03.00
0x402A:007
(P805.07)
Sequencer segment 5: Torque setpoint
(Segment 5: Torque setp.)
-400.0 ... [100.0] ... 400.0 %
From version 03.00
Torque setpoint for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Torque
mode [-1]".
0x402A:008
Sequencer segment 5: NetWordOUT2
0 ... [0] ... 65535
From version 03.00
Optionally: Set the NetWordOUT2 data word to the value set here for
the execution time of the segment.
The NetWordOUT2 data word 0x400A:002 (P591.02) can be mapped
to
a network register to transfer the set value as process date.
0x402A:009
Sequencer segment 5: Position setpoint
0 ... [0] ... 4294967295
From version 03.00
