The process controller provides different internal status signals. These status signals can
be
assigned to the relay, the digital outputs or the NetWordOUT1 status word. For details
see chapter "Configuration of digital outputs".
 429
Parameter
Name / value range / [default setting]
Info
0x400B:011
(P592.11)
Process input data: PID feedback
(Process data IN: PID feedback)
-300.00 ... [0.00] ... 300.00 PID unit
From version 03.00
Mappable parameter for the feedback of the variable (actual value) via
network.
Only effective with the selection "Network[5]" in 0x4020:002
(P600.02).
0x4020:001
(P600.01)
Process controller setup (PID): Operating mode
(PID setup: Operating mode)
Selection of the process controller operating mode.
0
Inhibited
Process controller deactivated.
1
Normal operation
The setpoint is higher than the fed back variable (actual value). If the
system deviation increases, the motor speed is increased.
Example: pressure-controlled booster pumps (increase in the motor
speed produces an increase in pressure.)
2 Reverse operation The setpoint is lower than the fed back variable (actual value). If the
system deviation increases, the motor speed is increased.
Example: temperature-
controlled cooling water pump (increase in motor
speed produces decrease in temperature.)
3
Normal bi-drectional
The direction of rotation corresponds to the sign of the system
deviation. If the system deviation increases, the motor speed is
increased.
4
Reverse bi-directional
A negative system deviation causes a positive direction of rotation. If
the system deviation increases, the motor speed is increased.
0x4020:002
(P600.02)
Process controller setup (PID): PID process variable
(PID setup: PID process var.)
Selection of the source via which the feedback of the controlled variable
(actual value) for the process controller is effected.
1
Analog input 1
2
Analog input 2
3
DC-bus voltage
(from version 02.00)
4
Motor Current
(from version 02.00)
5
Network
(from version 02.00)
6
HTL input
(from version 04.00)
Selection is not supported by the inverter Emotron VS10/30.
0x4020:003
(P600.03)
Process controller setup (PID): Closed-loop controlled
speed range
(PID setup: PID speed range)
0 ... [100] ... 100 %
Setting of the maximum output frequency up to which the process
controller carries out regulation.
•
100 % ≡ Maximum frequency 0x2916 (P211.00).
0x4020:004
(P600.04)
Process controller setup (PID): Speed feedforward
control source
(PID setup: PID line speed)
Optional selection of a speed feedforward control source for the
process controller.
Is advisable, for instance, for dancer position controls if the motor
speed must not fall below line speed (process controller output value
= line speed + controlled motor speed).
Standard applications usually do not require a speed feedforward
con
trol; therefore it is deactivated in the default setting.
0
Without speed addition
1 Keypad frequency setpoint
2
Analog input 1
3
Analog input 2
4
Frequency preset 1
5
Frequency preset 2
6 Frequency preset 3
7
Frequency preset 4
8
Network
0x4020:005
(P600.05)
Process controller setup (PID): Min speed limit
(PID setup: Min speed lim)
-100.0 ... [-100.0] ... 100.0 %
From version 03.00
Configuration of the process controller
•
100 % ≡ Maximum frequency 0x2916 (P211.00).
The limitation becomes effective after the line speed has been added.
The value set here also limits the I component of the PID controller
(Integrator-Anti-Windup).
0x4020:006
(P600.06)
Process controller setup (PID): Max speed limit
(PID setup: Max speed lim)
-100.0 ... [100.0] ... 100.0 %
From version 03.00
Maximum output value of the process controller.
•
100 % ≡ Maximum frequency 0x2916 (P211.00).
The limitation becomes effective after the line speed has been added.
The value set here also limits the I component of the PID controller
(Integrator-Anti-Windup).
