Name / value range / [default setting]
(P606.01)
PID speed operation: Acceleration time
(PID speed op.: Accel. time)
0.0 ... [1.0] ... 3600.0 s
Acceleration time for (temporary) speed-controlled drive control in
process controller mode.
The acceleration time takes effect at the output of the process
con
(P606.02)
PID speed operation: Deceleration time
(PID speed op.: Decel. time)
0.0 ... [1.0] ... 3600.0 s
Deceleration time for (temporary) speed-controlled drive control in
process controller mode.
The deceleration time takes effect at the output of the process
con
troller.
Exception: In case of quick stop, the quick stop delay time is effective.
(P601.00)
(PID P-component)
0.0 ... [5.0] ... 1000.0 %
Output frequency of the process controller per 1 % system deviation.
•
100 % ≡ maximum frequency 0x2916 (P211.00).
(P602.00)
(PID Icomponent)
10 ... [400] ... 6000 ms
Reset time for system deviation.
With the setting "6000 ms", the I component is deactivated.
The I component can also be deactivated via the "Inhibit process
con
troller I-component" 0x2631:047 (P400.47) function.
0x404A
(P603.00)
PID D-component
(PID D-component)
D component, does not respond to the rate of the system deviation, but
only to its rate of change.
(P604.00)
(PID setp.ramp)
0.0 ... [20.0] ... 100.0 s
Acceleration time and deceleration time for the process controller
setpoint, relating to the entire setting range of the process controller.
(P607.01)
PID influence: Acceleration time for showing
(PID influence: Show time)
0.0 ... [5.0] ... 999.9 s
If the trigger assigned in 0x2631:048 (P400.48) of the "Activate process
controller influence ramp" function is TRUE, the influence of the process
controller is shown by means of a ramp with the acceleration time set
(P607.02)
PID influence: Deceleration time for masking out
(PID influence: Mask out time)
0.0 ... [5.0] ... 999.9 s
If the trigger assigned in 0x2631:048 (P400.48) of the "Activate process
controller influence ramp" function is FALSE, the influence of the process
controller is hidden via a ramp with the deceleration time set here.
(P608.01)
PID alarms: MIN alarm threshold
(PID alarms: MIN alarm thrsh.)
-300.00 ... [0.00] ... 300.00 PID unit
Trigger threshold for the status signal "PID MIN alarm active [75]".
The "PID MIN alarm active [75]" status signal is TRUE if the fed back
variable (with activated PID control) is lower than the threshold set
here.
The status signal can be assigned to the relay, a digital output of the
NetWordOUT1 status word.
Configuration of digital outputs
429
(P608.02)
PID alarms: MAX alarm threshold
(PID alarms: MAX alarm thrsh.)
-300.00 ... [100.00] ... 300.00 PID unit
Trigger threshold for the status signal "PID MAX alarm active [76]".
The "PID MAX alarm active [76]" status signal is TRUE if the fed back
variable (with activated PID control) is higher than the threshold set
here.
The status signal can be assigned to the relay, a digital output of the
NetWordOUT1 status word.
Configuration of digital outputs
0x404D:003
(P608.03)
PID alarms: Monitoring bandwidth PID feedback
signal
(PID alarms: Bandw. feedback)
0.00 ... [2.00] ... 100.00 %
From version 04.00
Hysteresis for status signal "PID feedback = setpoint [73]".
100 % ≡ configured variable input range
Example: Variable input range 0 ... 10 V: 2 % ≡ 0.2 V
The status signal "PID feedback = setpoint [73]" is TRUE if the control
led
variable fed back = process controller setpoint (± hysteresis set here).
The status signal can be assigned to the relay, a digital output of the
NetWordOUT1 status word.
Configuration of digital outputs
429
(P605.01)
PID setpoint limits: Minimum setpoint
(PID setp. limit: Minimum setpoint)
-300.00 ... [-300.00] ... 300.00 PID unit
Minimum value of the process controller setpoint.
(P605.02)
PID setpoint limits: Maximum setpoint
(PID setp. limit: Maximum setpoint)
-300.00 ... [300.00] ... 300.00 PID unit
Maximum value of the process controller setpoint.
