Parameter
Name / value range / [default setting]
Info
0x2860:002
(P201.02)
PID control: Default setpoint source
(Stnd. setpoints: PID setp. src.)
Selection of the standard setpoint source for the reference value of the
PID control.
The selected standard setpoint source is always active with an activa
ted
PID control when no setpoint change-over to another setpoint
source via corresponding triggers/functions is active.
1
Keypad
The setpoint is specified locally by the keypad.
•
Default setting: 0x2601:002 (P202.02)
Use the
and navigation keys to change the keypad setpoint
(also during running operation).
2
Analog input 1
The setpoint is defined as analog signal via the analog input 1.
 Analog input 1

423
3 Analog input 2 The setpoint is defined as analog signal via the analog input 2.
 Analog input 2

427
5
Network
The setpoint is defined as process data object via the network.
 Configuring the network

166
11
PID preset 1
For the setpoint selection, preset values can be parameterised and
selected.
 Setpoint source of preset setpoints  386
12
PID preset 2
13 PID preset 3
14
PID preset 4
15
PID preset 5
16
PID preset 6
17
PID preset 7
18 PID preset 8
31
Segment preset 1
(from version 03.00)
For the setpoint selection, the segment presets parameterised for the
"sequencer" function can be selected as well.
 Sequencer  327
32
Segment preset 2
(from version 03.00)
33
Segment preset 3
(from version 03.00)
34
Segment preset 4
(from version 03.00)
35 Segment preset 5 (from version 03.00)
36
Segment preset 6
(from version 03.00)
37
Segment preset 7
(from version 03.00)
38
Segment preset 8
(from version 03.00)
50
Motor potentiometer
The setpoint is generated by the "motor potentiometer" function. This
function can be used as an alternative setpoint control which is
controlled via two signals: "MOP setpoint up" and "MOP setpoint
down".
 Motor potentiometer setpoint source (MOP)

392
0x401F:003
(P121.03)
Status
(PID status)
Read only
Bit-coded status display of the process controller.
Bit 0 Process controller off
Bit 1
PID output set to 0
Bit 2
PID I-component inhibited
Bit 3
PID influence shown
Bit 4
Setpoint = actual value
Bit 5 Idle state active
Bit 6
Reserved
Bit 7
Reserved
