Parameter
Name / value range / [default setting]
Info
0x400A:002
(P591.02)
Process output words: NetWordOUT2
Mappable data word for the output of messages of the "Sequencer"
function via network.
Configuration of the messages:
0x4026:008: NetWordOUT2 value for sequencer segment 1
0x4027:008: NetWordOUT2 value for sequencer segment 2
0x4028:008: NetWordOUT2 value for sequencer segment 3
0x4029:008: NetWordOUT2 value for sequencer segment 4
0x402A:008: NetWordOUT2 value for sequencer segment 5
0x402B:008: NetWordOUT2 value for sequencer segment 6
0x402C:008: NetWordOUT2 value for sequencer segment 7
0x402D:008: NetWordOUT2 value for sequencer segment 8
0x402E:008: NetWordOUT2 value for final segment
(NetWordOUTx: NetWordOUT2)
Read only
Bit
0
Mapping bit 0
Bit 1
Mapping bit 1
Bit
2
Mapping bit 2
Bit
3
Mapping bit 3
Bit
4
Mapping bit 4
Bit 5
Mapping bit 5
Bit
6
Mapping bit 6
Bit 7 Mapping bit 7
Bit 8
Mapping bit 8
Bit 9 Mapping bit 9
Bit 10
Mapping bit 10
Bit 11
Mapping bit 11
Bit 12
Mapping bit 12
Bit 13
Mapping bit 13
Bit 14
Mapping bit 14
Bit 15
Mapping bit 15
0x400B:003
(P592.03)
Process input data: Network setpoint frequency (0.1)
(Process data IN: Net.freq. 0.1)
0.0 ... [0.0] ... 599.0 Hz
Mappable parameter for specifying the frequency setpoint in [0.1 Hz]
via network.
The specification is made without sign (irrespective of the rotating
direction).
The rotating direction is specified via the control word.
Example: 456 ≡ 45.6 Hz
0x400B:004
(P592.04)
Process input data: Network setpoint speed
(Process data IN: Net.setp. speed)
0 ... [0] ... 50000 rpm
Mappable parameter for specifying the setpoint as speed in [rpm] via
network.
The specification is made without sign (irrespective of the rotating
direction).
The rotating direction is specified via the control word.
Example: 456 ≡ 456 rpm
0x400B:005
(P592.05)
Process input data: Network setpoint frequency
(0.01) (Process data IN: Net.freq. 0.01)
0.00 ... [0.00] ... 599.00 Hz
Mappable parameter for specifying the frequency setpoint in [0.01 Hz]
via network.
The specification is made without sign (irrespective of the rotating
direction).
The rotating direction is specified via the control word.
Example: 456 ≡ 4.56 Hz
0x400B:009
(P592.09)
Process input data: Torque scaling
(Process data IN: Torque scaling)
-128 ... [0] ... 127
From version 02.00
Scaling factor for torque setpoint 0x400B:008 (P592.08) and actual tor-
que value 0x400C:007 (P593.07) via network.
With the setting 0, no scaling takes place.
0x400B:012
(P592.12)
Process input data: Network setpoint frequency
[0.02Hz]
(Process data IN: NetSetfreq0.02Hz)
-29950 ... [0] ... 29950 Hz
From version 04.00
Mappable parameter for specifying the frequency setpoint in [0.02 Hz]
via network.
The specification is made without sign (irrespective of the rotating
direction).
The rotating direction is specified via the control word.
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
0x400C:003
(P593.03)
Process output data: Frequency (0.1)
(Process data OUT: Frequency (0.1))
Read only: x.x Hz
Mappable parameter for the output of the actual frequency value in
[0.1 Hz] via network.
The output is effected without sign (irrespective of the rotating
direc
tion).
The rotating direction is specified via the status word.
Example: 456 ≡ 45.6 Hz
