Emotron VS10 - Page 210

210 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x400C:004
(P593.04)
Process output data: Motor speed
(Process data OUT: Motor speed)
Read only: x rpm
Mappable parameter for the output of the actual value as speed in [rpm]
via network.
The output is effected without sign (irrespective of the rotating
direc
tion).
The rotating direction is specified via the status word.
Example: 456 ≡ 456 rpm
0x400C:005
(P593.05)
Process output data: Drive status
(Process data OUT: Drive status)
Read only
Mappable status word (Modbus Legacy Register 2003).
0
Error (non-resettable) active
1 Error active
2
Waiting for start
3
Identification not executed
4
Inverter disabled
5
Stop active
7
Identification active
8
Running
9
Acceleration active
10
Deceleration active
11 Deceleration override active
12
DC braking active
13
Flying start active
14
Current limit reached
16
Process controller idle state
0x400C:006
(P593.06)
Process output data: Frequency (0.01)
(Process data OUT: Frequency 0.01)
Read only: x.xx Hz
Mappable parameter for the output of the actual frequency value in
[0.01 Hz] via network.
The output is effected without sign (irrespective of the rotating
direc
tion).
The rotating direction is specified via the status word.
Example: 456 ≡ 4.56 Hz
0x400C:007
(P593.07)
Process output data: Torque scaled
(Process data OUT: Torque scaled)
Read only
From version 02.00
Mappable parameter for the output of the actual torque value in [Nm /
2
scaling factor
] via network.
The scaling factor can be set in 0x400B:009 (P592.09).
Actual torque value = scaled actual torque value (0x400C:007) / 2
scaling
factor
Example:
Scaled actual torque value (0x400C:007) = 345 [Nm]
Scaling factor (0x400B:009) = 3
Actual torque value = 345 [Nm] / 2
3
= 43.125 [Nm]
0x400C:008
(P593.08)
Process output data: Frequency [0.02 Hz]
(Process data OUT: Frequency 0.02Hz)
Read only: Hz
From version 04.00
Mappable parameter for the output of the actual frequency value in
[0.02 Hz] via network.
The output is effected without sign (irrespective of the rotating
direc
tion).
The rotating direction is specified via the status word.
Examples: 50 ≡ 1 Hz, 100 ≡ 2 Hz
