352 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x402B:001
(P806.01)
Sequencer segment 6: Frequency setpoint
(Segment 6: Frequency setp.)
-599.0 ... [0.0] ... 599.0 Hz
From version 03.00
Frequency setpoint for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
Direction of rotation according to sign.
0x402B:002
(P806.02)
Sequencer segment 6: Acceleration/deceleration
(Segment 6: Accel./decel.)
0.0 ... [5.0] ... 3600.0 s
From version 03.00
Acceleration/deceleration for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
The set time refers to the acceleration from standstill to the set
maxi
mum frequency. The deceleration is effected with the same
ramp.
0x402B:003
(P806.03)
Sequencer segment 6: Time
(Segment 6: Time)
0.0 ... [0.0] ... 100000.0 s
From version 03.00
Runtime for the segment after the expiry of which it is switched over to
the next step of the sequence.
Only relevant for Sequencer mode 0x4025 (P800.00) = "Time
opera
tion [1]" or "Time & step operation [3]".
With the setting "0.0", the segment will be skipped.
0x402B:004
(P806.04)
Sequencer segment 6: Digital outputs
(Segment 6: Digital outp.)
0 ... [0] ... 255
From version 03.00
Optionally: Set digital outputs to the level set here for the execution
time of the segment.
Note!
In order that the control of a digital output is executed by the
sequencer,
the following assignment must be made for the respective digital out-
put:
Relay: 0x2634:001 (P420.01) = "Sequencer controlled [100]"
Digital output 1: 0x2634:002 (P420.02) = "Sequencer controlled [100]"
Bit 0
Relay
0 = X9/NO-COM open and NC-COM closed.
1 = X9/NO-COM closed and NC-COM open.
An inversion set in 0x2635:001 (P421.01)
is taken into consideration
here.
Bit 1
Digital output 1
0 = set digital output 1 to LOW level.
1 = set digital output 1 to HIGH level.
An inversion set in 0x2635:002 (P421.02) is taken into consideration
here.
Bit 2
Digital output 2
Not availabl e for inverter Emotron VS10/30.
0x402B:005
(P806.05)
Sequencer segment 6: Analog outputs
(Segment 6: Analog outp.)
0.00 ... [0.00] ... 10.00 VDC
From version 03.00
Optionally: Set analog output to the voltage value set here for the
execu-
tion time of the segment.
Note!
In order that the control of the analog output is executed by the
sequencer, the following assignment must be made for the analog out-
put:
Analog output 1: 0x2639:002 (P440.02) = "Sequencer controlled [10]"
0x402B:006
(P806.06)
Sequencer segment 6: PID setpoint
(Segment 6: PID setp.)
-300.00 ... [0.00] ... 300.00 PID unit
From version 03.00
PID control value for the segment.
Only relevant if the PID control in 0x4020:001 (P600.01) is activated.
0x402B:007
(P806.07)
Sequencer segment 6: Torque setpoint
(Segment 6: Torque setp.)
-400.0 ... [100.0] ... 400.0 %
From version 03.00
Torque setpoint for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Torque
mode [-1]".
0x402B:008
Sequencer segment 6: NetWordOUT2
0 ... [0] ... 65535
From version 03.00
Optionally: Set the NetWordOUT2 data word to the value set here for
the execution time of the segment.
The NetWordOUT2 data word 0x400A:002 (P591.02) can be mapped
to
a network register to transfer the set value as process date.
0x402B:009
Sequencer segment 6: Position setpoint
0 ... [0] ... 4294967295
From version 03.00
0x402C:001
(P807.01)
Sequencer segment 7: Frequency setpoint
(Segment 7: Frequency setp.)
-599.0 ... [0.0] ... 599.0 Hz
From version 03.00
Frequency setpoint for the segment.
Only relevant for operating mode 0x6060 (P301.00) = "MS: Velocity
mode [-2]".
Direction of rotation according to sign.
