Motor connection
Inverter
VS10-23-1P7 VS10-23-2P4 VS10-23-3P2 VS10-23-4P2 VS10-23-6P0 VS10-23-7P0 VS10-023-9P6
Connection
X105
Connection type
pluggable screw terminal
Min. cable cross-section
mm²
1
Max. cable cross-section
mm²
2.5
Stripping length mm 8
Tightening torque
Nm
0.5
Required tool
0.5 x 3.0
Connection
PE
Connection type
PE screw
Min. cable cross-section mm² 1
Max. cable cross-section
mm²
6
Stripping length
mm
10
Tightening torque
Nm
1.2
Required tool
0.8 x 5.5
