Internal status signals
The sequencer provides different internal status signals (see the following table). These
status
signals can be assigned to the relay, the digital outputs or the status word.
 Configuration of digital outputs  429
Internal status signal
Info
"Sequencer controlled [100]"
The control is executed via the sequencer (according to the configuration of the digital outputs for the current
segment).
"Sequence active [101]"
The sequence is running and is currently not suspended.
"Sequence suspended [102]"
The sequence is currently suspended.
"Sequence done [103]"
The sequence is completed (end segment was passed through).
