Commissioning
For commissioning the sequencer, we recommend the following proceeding:
1. Configure segments (including end segment).
Details:
Segment configuration
329
2. Configure sequences:
• Assign the segments to the single steps of a sequence.
• Set the number of cycles for the respective sequence.
Details:
Sequence configuration
339
3. Make the basic setting of the sequencer:
• Set the desired operating mode (time and/or step operation).
• Optionally: Adapt end of sequence mode and start of sequence mode.
Details:
Sequencer basic settings
354
4. Configure the control of the sequencer:
• Assign the functions for selecting a sequence to suitable triggers (e. g. digital
inputs).
• Assign the functions for controlling the sequencer (start, stop, cancel, ...) to suitable
triggers.
Details:
Sequencer control functions
416
Control
The functions listed in the following table serve to control the sequencer. For details, see
chapter "Sequencer control functions". 416
Select sequence (bit 0) ... Select
sequence (bit 3)
Bit coded selection of the sequence to be started.
The selected sequence is started. The start can take place edge or status-controlled depending on the
configuration.
Immediate jump to the next step irrespective of the time set for the segment.
The sequencer stops in the current step. The expiration for the time set for the segment is stopped. The
sequencer setpoint remains active.
There is a temporal return to the normal setpoint control. The sequence is then continued at the point where
it was suspended.
Direct jump to the end segment. The further execution depends on the selected end of sequence mode.
Immediate return to the normal setpoint control. The end segment is not executed anymore.
Diagnostics
For diagnosing the sequencer, the diagnostic parameters listed in chapter "Sequencer
diag
nostics" are available.
80
