8
Not connected
0x2634:018 (P420.18)
9
Not connected
0x2634:019 (P420.19)
10 Setpoint speed reached 0x2634:020 (P420.20)
11
Current limit reached
0x2634:021 (P420.21)
12
Actual speed = 0
0x2634:022 (P420.22)
13
Rotational direction reversed
0x2634:023 (P420.23)
14
Release holding brake
0x2634:024 (P420.24)
15 Safe torque off (STO) active 0x2634:025 (P420.25)
The following parameters can be used to change the status assignment of the
NetWordOUT1 data word.
Parameter
Name / value range / [default setting]
Info
0x2634:010
(P420.10)
Digital outputs function: NetWordOUT1 bit 0
(Dig.out.function: NetWordOUT1.00)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 0 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
51
Ready for operation
TRUE if inverter is ready for operation (no error active, no STO active
and DC-bus voltage ok). Otherwise FALSE.
0x2634:011
(P420.11)
Digital outputs function: NetWordOUT1 bit 1
(Dig.out.function: NetWordOUT1.01)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 1 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2634:012
(P420.12)
Digital outputs function: NetWordOUT1 bit 2
(Dig.out.function: NetWordOUT1.02)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 2 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
52
Operation enabled
TRUE if inverter and start are enabled. Otherwise FALSE.
0x2634:013
(P420.13)
Digital outputs function: NetWordOUT1 bit 3
(Dig.out.function: NetWordOUT1.03)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 3 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
56
Error active
TRUE if error is active. Otherwise FALSE.
0x2634:014
(P420.14)
Digital outputs function: NetWordOUT1 bit 4
(Dig.out.function: NetWordOUT1.04)
For further possible settings, see parameter
0x2634:001 (P420.01).

429
Assignment of a trigger to bit 4 of NetWordOUT1.
Trigger = FALSE: bit set to 0.
Trigger = TRUE: bit set to 1.
0 Not connected No trigger assigned (trigger is constantly FALSE).
