Parameter
Name / value range / [default setting]
Info
115
Release holding brake
Trigger signal for releasing the holding brake (TRUE = release holding
brake).
Note!
If this trigger is assigned to the relay or a digital output, the deceleration
times set for the respective output are not effective (are internally set to
"0"). Only the deceleration time set in 0x2820:012 (P712.12) for closing
the holding brake influences in this case the time-dependent behaviour
of the output.
 Holding brake control

302
117
Motor phase failure
TRUE if a motor phase failure has been detected. Otherwise FALSE.
 Motor phase failure detection

163
0x2635:001
(P421.01)
Inversion of digital outputs: Relay
(DO inversion: Relay inverted)
Relay inversion
0
Not inverted
1 Inverted
0x4018:003
Relay: Switch-off delay
0.000 ... [0.000] ... 65.535 s
Switch-off delay for the relay.
Note!
The set delay time is not effective (internally set to "0") if the relay is
assigned to the trigger "Release holding brake [115]". Only the
deceleration time set in 0x2820:012 (P712.12)
for closing the holding
brake influences the time-dependent behaviour of the relay.
0x4018:004
Relay: Switch-on delay
0.000 ... [0.000] ... 65.535 s
Switch-on delay for the relay.
Note!
The set delay time is not effective (internally set to "0") if the relay is
assigned to the trigger "Release holding brake [115]". Only the
deceleration time set in 0x2820:012 (P712.12)
for closing the holding
brake influences the time-dependent behaviour of the relay.
0x4018:005
Relay: Relay state
Read only
Display of the logic state of the relay.
0
FALSE
1
TRUE
0x4018:006
Relay: Trigger signal state
Read only
Display of the logic state of the trigger signal for the relay (without
taking a ON/OFF delay set and inversion into consideration).
0
FALSE
1
TRUE
0x4018:007
Relay: Switching cycles
Read only
Display of the previous relay switching cycles.
