Emotron VS10 - Page 40

40 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2860:001
(P201.01)
Frequency control: Default setpoint source
(Stnd. setpoints: Freq. setp. src.)
Selection of the standard setpoint source for operating mode "MS:
Velocity mode".
•
The selected standard setpoint source is always active in the
operat
ing mode 0x6060 (P301.00) = "MS: Velocity mode [-2]"
when no setpoint change-over to another setpoint source via
corresponding triggers/functions is active.
 Setpoint change-over

378
1
Keypad
The setpoint is specified locally by the keypad.
•
Default setting: 0x2601:001 (P202.01)
•
Use the and navigation keys to change the keypad
setpoint (also during running operation).
2
Analog input 1
The setpoint is defined as analog signal via the analog input 1.
 Analog input 1

423
3
Analog input 2
The setpoint is defined as analog signal via the analog input 2.
 Analog input 2

427
5
Network
The setpoint is defined as process data object via the network.
 Configuring the network

166
11
Frequency preset 1
For the setpoint selection, preset values can be parameterised and
selected.
 Setpoint source of preset setpoints  386
12
Frequency preset 2
13 Frequency preset 3
14
Frequency preset 4
15
Frequency preset 5
16
Frequency preset 6
17
Frequency preset 7
18 Frequency preset 8
19
Frequency preset 9
20
Frequency preset 10
21
Frequency preset 11
22
Frequency preset 12
23 Frequency preset 13
24
Frequency preset 14
25
Frequency preset 15
31
Segment preset 1
(from version 03.00)
For the setpoint selection, the segment presets parameterised for the
"sequencer" function can be selected as well.
 Sequencer  327
32
Segment preset 2
(from version 03.00)
33 Segment preset 3 (from version 03.00)
34
Segment preset 4
(from version 03.00)
35
Segment preset 5
(from version 03.00)
36
Segment preset 6
(from version 03.00)
37
Segment preset 7
(from version 03.00)
38 Segment preset 8 (from version 03.00)
50
Motor potentiometer
The setpoint is generated by the "motor potentiometer" function. This
function can be used as an alternative setpoint control which is
controlled via two signals: "MOP setpoint up" and "MOP setpoint
down".
 Motor potentiometer setpoint source (MOP)

392
0x2911:001
(P450.01)
Frequency setpoint presets: Preset 1
(Freq. presets: Freq. preset 1)
0.0 ... [20.0] ... 599.0 Hz
Parameterisable frequency setpoints (presets) for operating mode
"MS: Velocity mode".
0x2911:002
(P450.02)
Frequency setpoint presets: Preset 2
(Freq. presets: Freq. preset 2)
0.0 ... [40.0] ... 599.0 Hz
0x2911:003
(P450.03)
Frequency setpoint presets: Preset 3
(Freq. presets: Freq. preset 3)
Device for 50-Hz mains: 0.0 ... [50.0] ... 599.0 Hz
Device for 60-Hz mains: 0.0 ... [60.0] ... 599.0 Hz
