Emotron VS10 - Page 383

Parameter
Name / value range / [default setting]
Info
0x2631:002
(P400.02)
Function list: Run
(Function list: Run)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run" function.
Function 1: Start / stop motor (default setting)
Function 1 is active if no further start commands (start forward/start
reverse) have been
connected to triggers, no keypad control is active and
no network control is active.
Trigger = TRUE: Let motor rotate forward (CW).
Trigger = FALSE: Stop motor.
Notes to function 1:
If "Enable inverter" 0x2631:001 (P400.01) is set = "Constant TRUE [1]",
the only permissible trigger for this function is a digital input in order
that the motor can be stopped again any time.
The stop method can be selected in 0x2838:003 (P203.03).
The function also serves to realise an automatic start after switch-on.
 Starting performance  97
Function 2: Start enable/stop motor
Function 2 is active if further start commands have been connected to
triggers, keypad control is active or network control is active.
Trigger = TRUE: Start commands of the active control source are
enabled.
Trigger = FALSE: Stop motor.
Notes to function 2:
If no separate start enable is required for the application, the trigger
"Constant TRUE [1]" must be set.
The stop method can be selected in 0x2838:003 (P203.03).
11
Digital input 1
State of X3/DI1, taking an inversion set in 0x2632:001 (P411.01) into
consideration.
0x2631:003
(P400.03)
Function list: Activate quick stop
(Function list: Quick stop)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Activate quick stop" function.
Trigger = TRUE: Activate quick stop.
Trigger = FALSE: Deactivate quick stop.
Notes:
The "Quick stop" function brings the motor to a standstill within the
deceleration time set in 0x291C (P225.00).
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:006
(P400.06)
Function list: Start forward (CW)
(Function list: Start forward)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Start forward (CW)" function.
Trigger = FALSE↗TRUE (edge): Let motor rotate forward.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
After the start, the motor runs until "Run" is set to FALSE, another
stop command is given or the inverter is disabled.
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:007
(P400.07)
Function list: Start reverse (CCW)
(Function list: Start reverse)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Start reverse (CCW)" function
Trigger = FALSE↗TRUE (edge): Let motor rotate backward.
Trigger = TRUE↘FALSE (edge): No action.
Notes:
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
After the start, the motor runs until "Run" is set to FALSE, another
stop command is given or the inverter is disabled.
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
