Emotron VS10 - Page 382

382 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
79
Torque limit reached
(from version 02.00)
TRUE if torque limit has been reached or exceeded. Otherwise FALSE.
Setting "Positive torque limit" in 0x60E0.
Setting "Negative torque limit" in 0x60E1.
81
Error of analog input 1 active
TRUE if the monitoring of the input signal at the analog input 1 has
responded. Otherwise FALSE.
This trigger is set as a function of the following settings:
Monitoring threshold 0x2636:008 (P430.08)
Monitoring condition 0x2636:009 (P430.09)
The setting of the Error response in 0x2636:010 (P430.10) has no effect
on this trigger.
 Analog input 1

423
82
Error of analog input 2 active
TRUE if the monitoring of the input signal at the analog input 2 has
responded. Otherwise FALSE.
This trigger is set as a function of the following settings:
Monitoring threshold 0x2637:008 (P431.08)
Monitoring condition 0x2637:009 (P431.09)
The setting of the Error response in 0x2637:010 (P431.10) has no effect
on this trigger.
 Analog input 2

427
83
Load loss detected
TRUE if actual motor current < threshold for load loss detection after
delay time of the load loss detection has elapsed. Otherwise FALSE.
Display of the present motor current in 0x6078 (P103.00).
Setting Threshold in 0x4006:001 (P710.01).
Setting Decelerationin 0x4006:002 (P710.02).
 Load loss detection

270
102
Sequence suspended
(from version 03.00)
Status signal of the "sequencer" function:
TRUE if the sequence is currently suspended.
 Sequencer

327
103 Sequence done (from version 03.00) Status signal of the "sequencer" function:
TRUE if the sequence is completed (final segment has been passed
through).
 Sequencer

327
104
Local control active
TRUE if local keypad control ("LOC") active. Otherwise FALSE.
105
Remote control active
TRUE if remote control ("REM") via terminals, network, etc. active.
Otherwise FALSE.
106
Manual setpoint selection active
TRUE if manual setpoint selection ("MAN") via keypad active. Otherwise
FALSE.
Selection of the trigger for the "Activate keypad setpoint" function in
0x2631:016 (P400.16).
107
Automatic setpoint selection active
TRUE if automatic setpoint selection ("AUTO") via terminals, network,
etc. active. Otherwise FALSE.
