Parameter
Name / value range / [default setting]
Info
0x2636:001
(P430.01)
Analog input 1: Input range
(Analog input 1: AI1 input range)
Definition of the input range.
0 0 ... 10 VDC
1
0 ... 5 VDC
2
2 ... 10 VDC
4
4 ... 20 mA
5
0 ... 20 mA
0x2636:002
(P430.02)
Analog input 1: Min frequency value
(Analog input 1: AI1 freq @ min)
-1000.0 ... [0.0] ... 1000.0 Hz
Definition of the setting range for operating mode "MS: Velocity mode".
Direction of rotation according to sign.
The standard setpoint source for operating mode 0x6060 (P301.00) =
"MS: Velocity mode [-2]" is selected in 0x2860:001 (P201.01).
0x2636:003
(P430.03)
Analog input 1: Max frequency value
(Analog input 1: AI1 freq @ max)
Device for 50-Hz mains: -1000.0 ... [50.0] ... 1000.0 Hz
Device for 60-Hz mains: -1000.0 ... [60.0] ... 1000.0 Hz
0x2636:004
(P430.04)
Analog input 1: Min PID value
(Analog input 1: AI1 PID @ min)
-300.00 ... [0.00] ... 300.00 PID unit
Definition of the setting range for PID control.
The standard setpoint source for the reference value of PID control is
selected in 0x2860:002 (P201.02).
0x2636:005
(P430.05)
Analog input 1: Max PID value
(Analog input 1: AI1 PID @ max)
-300.00 ... [100.00] ... 300.00 PID unit
0x2636:006
(P430.06)
Analog input 1: Filter time
(Analog input 1: AI1 filter time)
0 ... [10] ... 10000 ms
PT1 time constant for low-pass filter.
By the use of a low-pass filter, the impacts of noise to an analog signal
can be minimised.
For an optimum filter effect, first the noise frequency has to be
deter
mined. The time constant then has to be set so that it equals
the reciprocal value of the double frequency.
0x2636:007
(P430.07)
Analog input 1: Dead band
(Analog input 1: AI1 dead band)
0.0 ... [0.0] ... 100.0 %
Optional setting of a dead band that is placed symmetrically around the
frequency zero point.
The value set defines half the width of the dead band in [%].
Example: Setting 2 % results in a dead band of 4 %.
If the analog input value is within the dead band, the output value for
the motor control is set to "0".
0x2636:008
(P430.08)
Analog input 1: Monitoring threshold
(Analog input 1: AI1 monit.level)
-100.0 ... [0.0] ... 100.0 %
Monitoring threshold for analog input 1.
100 % ≡ 10 V (with configuration as voltage input)
100 % ≡ 20 mA (with configuration as current loop)
0x2636:009
(P430.09)
Analog input 1: Monitoring condition
(Analog input 1: AI1 monit.cond.)
Monitoring condition for analog input 1.
If the selected condition is met, the "Error of analog input 1 active
[81]" trigger is set to TRUE. The trigger can be assigned to a function
or a digital output.
If the selected condition is met for at least 500 ms, the error response
set in 0x2636:010 (P430.10) takes place.
0
Input value < trigger threshold
1
Input value > trigger threshold
0x2636:010
(P430.10)
Analog input 1: Error response
(Analog input 1: AI1 error resp.)
For further possible settings, see parameter
0x2D45:001 (P310.01).  163
Error response for analog input 1.
The selected response takes place if the monitoring condition selected
in
0x2636:009 (P430.09) is met for at least 500 ms.
Associated error code:
28801 | 0x7081 Analog input 1 fault
3
Fault

Error types
 84
0x2636:011
(P430.11)
Analog input 1: Min torque value
(Analog input 1: Min. torque)
-400.0 ... [0.0] ... 400.0 %
From version 03.00
Definition of the setting range for operating mode "MS: Torque mode".
100 % ≡ permissible maximum torque 0x6072 (P326.00)
Direction of rotation according to sign.
The standard setpoint source for operating mode 0x6060 (P301.00) =
"MS: Torque mode [-1]" is selected in 0x2860:003 (P201.03).
 Torque control w/ freq. limit  147
0x2636:012
(P430.12)
Analog input 1: Max torque value
(Analog input 1: Max. torque)
-400.0 ... [100.0] ... 400.0 %
From version 03.00
