384 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2631:008
(P400.08)
Function list: Run forward (CW)
(Function list: Run forward)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run forward (CW)" function.
Trigger = TRUE: Let motor rotate forward.
Trigger = FALSE: Stop motor.
Notes:
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
The inverter always responds to the run command detected last (if
start enable is available).
The stop method can be selected in 0x2838:003 (P203.03).
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
The "Run forward (CW)" function also serves to realise an automatic
start after switch-on.
 Starting performance  97
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:009
(P400.09)
Function list: Run reverse (CCW)
(Function list: Run reverse)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Run reverse (CCW)" function.
Trigger = TRUE: Let motor rotate backward.
Trigger = FALSE: Stop motor.
Notes:
In order to start the motor, "Enable inverter" 0x2631:001 (P400.01)
and "Run" 0x2631:002 (P400.02) must be set to TRUE.
The inverter always responds to the run command detected last (if
start enable is available).
The stop method can be selected in 0x2838:003 (P203.03).
In the case of a bipolar setpoint selection (e.g ±10 V), the function is
executed irrespective of the rotating direction. The rotating direction
is determined by the sign of the setpoint.
The "Run reverse (CCW)" function also serves to realise an automatic
start after switch-on.
 Starting performance  97
0
Not connected
No trigger assigned (trigger is constantly FALSE).
0x2631:010
(P400.10)
Function list: Jog foward (CW)
(Function list: Jog foward)
Setting can only be changed if the inverter is
inhibi
ted.
For further possible settings, see parameter
0x2631:001 (P400.01).  364
Assignment of a trigger for the "Jog foward (CW)" function.
Trigger = TRUE: Let motor rotate forward with preset 5.
Trigger = FALSE: Stop motor.
CAUTION!
The jog operation has a higher priority than the "Run" function, all other
start commands and the keypad key
.
If jog operation is active, the motor cannot be stopped with the
previ
ously mentioned functions!
However, jog operation can be interrupted by the "Quick stop"
func
tion.
Notes:
The preset value 5 can be set in 0x2911:005 (P450.05).
The stop method can be selected in 0x2838:003 (P203.03).
If "Jog foward (CW)" and "Jog reverse (CCW)" are activated at the
same
time, the motor is stopped using the stop method and jog operation
must be triggered again.
Jog operation cannot be started automatically. The "Start at power
up"
option in 0x2838:002 (P203.02) does not apply to jog operation.
0
Not connected
No trigger assigned (trigger is constantly FALSE).
