84 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
4
Jog operation
"Jog foward (CW)" or "Jog reverse (CCW)" function active.
0x2831 Inverter status word
Read only
Bit-coded status word of the internal motor control.
Bit 1
Speed 1 limited
1 ≡ input of speed controller 1 in limitation.
Bit 2 Speed limited 1 ≡ output of speed controller 1 in limitation.
Bit 3
Torque limited
1 ≡ setpoint torque in limitation.
Bit 4
Current limited
1 ≡ setpoint current in limitation.
Bit 5
Speed 2 limited
1 ≡ input of the speed controller 2 in "torque mode" in limitation.
Bit 6
Upper speed limit active
1 ≡ in "torque mode", the speed is limited to upper speed limit
0x2946:001 (P340.01).
Bit 7
Lower speed limit active
1 ≡ in "torque mode", the speed is limited to lower speed
limit0x2946:002 (P340.02).
Bit 10
Output frequency limited
1 ≡ setpoint frequency with V/f operation in limitation.
Bit 11
Magnetisation completed
1 ≡ during V/f operation, the factor 7 rotor time constant has passed
(calculated from the time at which the inverter was enabled without
restart on the fly and with a total motor current of 20 % rated motor
current for the first time). Otherwise 0.
Bit 12
Motor phase error
1 ≡ motor phase failure detection active.
Bit 14
Error reset blocking time active
1 ≡ the fault can only be reset when the blocking time has elapsed.
0x2833
Inverter status word 2
Read only
Bit-coded status word 2 of the inverter.
Bit 1 Manual test mode active 1 ≡ manual test mode active.
Bit 2
Manual control active
1 ≡ manual control active.
Bit 6
DC braking active
1 ≡ DC braking active.
0x2DAC
(P119.00)
Keypad status (Keypad status)
Read only
Bit-coded display of the keypad status.
Bit 0
Start Key
1 ≡ keypad start key pressed.
Bit 1
Stop Key
1 ≡ keypad stop key pressed.
Bit 2
Up arrow
1 ≡ keypad up-arrow key pressed.
Bit 3 Down arrow 1 ≡ keypad down-arrow key pressed.
Bit 4
Enter Key
1 ≡ keypad enter key pressed.
Bit 5
Back key
1 ≡ keypad back key pressed.
0x2DAD
(P120.00)
Internal hardware states (Int. HW states)
Read only
Bit-coded display of internal hardware states.
Bit 0
Relay
0 ≡ X9/NO-COM open and NC-COM closed. 1 ≡ X9/NO-COM closed and
NC-COM open.
Bit 1
Digital output 1
0 ≡ LOW level, 1 ≡ HIGH level.
Bit 2
Digital output 2
Bit 10
Charge Relay
1 ≡ precharging of the DC bus via charge relay is active.
0x603F
(P150.00)
Error code (Error code)
Read only
Error message
