Parameter
Name / value range / [default setting]
Info
0x282B:002
(P125.02)
Inverter diagnostics: Active setpoint source (Inverter
diag.: Active setpoint)
Read only
Display of the setpoint source that is currently active.
0
Not selected
1
Analog input 1
2
Analog input 2
3 Keypad Setpoint
4
HTL input
5
Network Setpoint
11
Setpoint preset 1
12
Setpoint preset 2
13 Setpoint preset 3
14
Setpoint preset 4
15
Setpoint preset 5
16
Setpoint preset 6
17
Setpoint preset 7
18 Setpoint preset 8
19
Setpoint preset 9
20
Setpoint preset 10
21
Setpoint preset 11
22
Setpoint preset 12
23 Setpoint preset 13
24
Setpoint preset 14
25
Setpoint preset 15
31
Segment preset 1
32
Segment preset 2
33 Segment preset 3
34
Segment preset 4
35
Segment preset 5
36
Segment preset 6
37
Segment preset 7
38 Segment preset 8
39
Last segment
50
Motor potentiometer
51
PID setpoint
From version 04.00
0x282B:003
(P125.03)
Inverter diagnostics: Keypad LCD status (Inverter
diag.: Keypad LCD stat.)
Read only
Bit-coded state of the keypad status displays.
Bit 0 LOC 1 ≡ local keypad control active.
Bit 1
REM
1 ≡ remote control via terminals, network, etc. active.
Bit 2
MAN
1 ≡ manual setpoint selection via keypad active.
Bit 3
Auto
1 ≡ automatic setpoint selection via terminals, network, etc. active.
Bit 4
Set
1 ≡ a parameter setting has been changed but not been saved yet in the
memory module with mains failure protection.
0x282B:004
(P125.04)
Inverter diagnostics: Active drive mode (Inverter
diag.: Drive mode)
Read only
Display of the active drive mode.
0 Velocity mode "Velocity mode" active.
1
PID control
PID control active.
2
Torque mode
From version 03.00
"Torque mode" active.
