92 01-6203-01R3, CG Drives & Automation
Parameter
Name / value range / [default setting]
Info
0x2DA5:016
(P111.16)
Diagnostics of analog input 2: Status (AI2 diagnostics:
AI2 status)
Read only
From version 04.00
Bit-coded display of the status of analog input 2 (X3/AI2).
Bit 0 Mode 0: 0 ... 10 VDC active
Bit 1
Mode 1: 0 ... 5 VDC active
Bit 2
Mode 2: 2 ... 10 VDC active
Bit 3
Mode 3: -10 ... 10 VDC active
Bit 4
Mode 4: 4 ... 20 mA active
Bit 5 Mode 5: 0 ... 20 mA active
Bit 6
24 V supply OK
Bit 7
Calibration successful
Bit 8
Monitoring threshold exceeded/not
reached
Bit 9
Input current too low
Bit 10
Input voltage too low
Bit 11
Input voltage too high
0x2DAA:001
(P112.01)
Diagnostics of analog output 1: Voltage (AO1
diagnostics: AO1 Voltage)
Read only: x.xx V
Display of the current output voltage at X3/AO1.
0x2DAA:002
(P112.02)
Diagnostics of analog output 1: Current (AO1
diagnostics: AO1 Current)
Read only: x.xx mA
Display of the present output current at X3/AO1.
Related topics
 Configuration of analog inputs  423
 Configuration of analog outputs  437
