148 01-6203-01R3, CG Drives & Automation
Additionally, the filter time for the slip compensation can be adapted in 0x2B09:002
(P315.02) if required. The preset filter time is adapted to typical motors. If full load or
nearly full load oscillations or instabilities occur, we recommend an increase of the filter
time.
Parameter Name / value range / [default setting] Info
0x2B09:001
(P315.01)
Slip compensation: Gain
(Slip compens.: Slip: gain)
-200.00 ... [100.00] ... 200.00 %
Adjustment in percent of the slip calculated.
•
For instance required for deviations of the real motor data from
the
nameplate data.
•
A setting of 100 % corresponds to the rated slip of the machine in
the
nominal operating point.
0x2B09:002
(P315.02)
Slip compensation: Filter time
(Slip compens.: Filter time)
1 ... [5] ... 6000 ms
Filter time for the slip compensation.
•
The preset filter time is adapted to typical motors.
0x2C02:004
(P351.04)
Slip frequency (Slip
frequency)
• Read only: x.x Hz
Display of the rated slip determined.
0x2C01:001
Motor parameters: Number
of pole pairs
• Read only
Display of the number of pole pairs calculated from the rated speed
and rated frequency.
0x2C01:004
(P320.04)
Motor parameters: Rated
speed (Motor parameters:
Rated speed)
Device for 50-Hz mains: 50 ...
[1450] ... 50000 rpm Device
for 60-Hz mains: 50 ... [1750]
... 50000 rpm
General motor data.
Carry out settings as specified by motor nameplate data.
Note!
When you enter the motor nameplate data, take into account the
phase connection implemented for the motor (star or delta
connection). Only enter the data applying to the connection type
selected.
0x2C01:005
(P320.05)
Motor parameters: Rated
frequency (Motor
parameters: Rated frequency)
Device for 50-Hz mains: 1.0 ...
[50.0] ... 1000.0 Hz
Device for 60-Hz mains: 1.0 ...
[60.0] ... 1000.0 Hz
