218 01-6203-01R3, CG Drives & Automation
The inverter can be configured as producer or as consumer to monitor up to four other
nodes.
Parameter
Name / value range / [default setting]
Info
0x1016:000
(P520.00)
Consumer heartbeat time: Highest sub-index suppor-
ted
(Cons. heartbeat: Highest subindex)
Read only
Highest subindex, permanently set to 4. Corresponds at the same time
to the maximum possible number of nodes to be monitored.
0x1016:001
(P520.01)
Consumer heartbeat time: Consumer heartbeat time
1
(Cons. heartbeat: Cons. heartbeat1)
0x00000000 ... [0x00000000] ... 0x00FFFFFF
Node ID and heartbeat time of node 1 which is to be monitored.
Format: 0x00nnhhhh (nn = node ID, hhhh = heartbeat time in [ms])
0x1016:002
(P520.02)
Consumer heartbeat time: Consumer heartbeat time
2
(Cons. heartbeat: Cons. heartbeat2)
0x00000000 ... [0x00000000] ... 0x00FFFFFF
Node ID and heartbeat time of node 2 which is to be monitored.
Format: 0x00nnhhhh (nn = node ID, hhhh = heartbeat time in [ms])
0x1016:003
(P520.03)
Consumer heartbeat time: Consumer heartbeat time
3
(Cons. heartbeat: Cons. heartbeat3)
0x00000000 ... [0x00000000] ... 0x00FFFFFF
Node ID and heartbeat time of node 3 which is to be monitored.
Format: 0x00nnhhhh (nn = node ID, hhhh = heartbeat time in [ms])
0x1016:004
(P520.04)
Consumer heartbeat time: Consumer heartbeat time
4
(Cons. heartbeat: Cons. heartbeat4)
0x00000000 ... [0x00000000] ... 0x00FFFFFF
Node ID and heartbeat time of node 4 which is to be monitored.
Format: 0x00nnhhhh (nn = node ID, hhhh = heartbeat time in [ms])
0x1017
(P522.00)
Producer heartbeat time
(Prod. heartbeat)
0 ... [0] ... 65535 ms
Time interval for the transmission of the heartbeat telegram to the
consumer(s).
The heartbeat telegram is sent automatically as soon as a time > 0 ms
is
set.
The set time is internally rounded up to the next multiple of 10 ms.
