Emotron VS10 - Page 225

Parameter
Name / value range / [default setting]
Info
0x1601:000
RPDO2 mapping parameter: Number of mapped
application objects in PDO
0 ... [0] ... 8
Number of objects mapped in RPDO2.
0x1601:001
RPDO2 mapping parameter: Application object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 1 for RPDO2.
0x1601:002
RPDO2 mapping parameter: Application object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 2 for RPDO2.
0x1601:003
RPDO2 mapping parameter: Application object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for RPDO2.
0x1601:004
RPDO2 mapping parameter: Application object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for RPDO2.
0x1601:005
RPDO2 mapping parameter: Application object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for RPDO2.
0x1601:006
RPDO2 mapping parameter: Application object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for RPDO2.
0x1601:007
RPDO2 mapping parameter: Application object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for RPDO2.
0x1601:008 RPDO2 mapping parameter: Application object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for RPDO2.
0x1602:000
RPDO3 mapping parameter: Number of mapped
application objects in PDO
0 ... [0] ... 8
Number of objects mapped in RPDO3.
0x1602:001
RPDO3 mapping parameter: Application object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 1 for RPDO3.
0x1602:002
RPDO3 mapping parameter: Application object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 2 for RPDO3.
0x1602:003
RPDO3 mapping parameter: Application object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for RPDO3.
0x1602:004
RPDO3 mapping parameter: Application object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for RPDO3.
0x1602:005
RPDO3 mapping parameter: Application object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for RPDO3.
0x1602:006 RPDO3 mapping parameter: Application object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for RPDO3.
0x1602:007
RPDO3 mapping parameter: Application object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for RPDO3.
0x1602:008 RPDO3 mapping parameter: Application object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for RPDO3.
0x1A00:000
TPDO1 mapping parameter: Number of mapped
application objects in TPDO
0 ... [2] ... 8
Number of objects mapped in TPDO1.
0x1A00:001
TPDO1 mapping parameter: Application object 1
0x00000000 ... [0x60410010] ... 0xFFFFFFFF
Mapping entry 1 for TPDO1.
0x1A00:002
TPDO1 mapping parameter: Application object 2
0x00000000 ... [0x60440010] ... 0xFFFFFFFF
Mapping entry 2 for TPDO1.
0x1A00:003
TPDO1 mapping parameter: Application object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for TPDO1.
0x1A00:004 TPDO1 mapping parameter: Application object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for TPDO1.
0x1A00:005
TPDO1 mapping parameter: Application object 5
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 5 for TPDO1.
0x1A00:006
TPDO1 mapping parameter: Application object 6
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 6 for TPDO1.
0x1A00:007
TPDO1 mapping parameter: Application object 7
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 7 for TPDO1.
0x1A00:008
TPDO1 mapping parameter: Application object 8
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 8 for TPDO1.
0x1A01:000
TPDO2 mapping parameter: Number of mapped
application objects in TPDO
0 ... [0] ... 8
Number of objects mapped in TPDO2.
0x1A01:001
TPDO2 mapping parameter: Application object 1
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 1 for TPDO2.
0x1A01:002
TPDO2 mapping parameter: Application object 2
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 2 for TPDO2.
0x1A01:003
TPDO2 mapping parameter: Application object 3
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 3 for TPDO2.
0x1A01:004
TPDO2 mapping parameter: Application object 4
0x00000000 ... [0x00000000] ... 0xFFFFFFFF
Mapping entry 4 for TPDO2.
