Mains connection
Inverter
VS30-40-1P3 VS30-40-1P8 VS30-40-2P4 VS30-40-3P2 VS30-40-3P9 VS30-40-5P6
Connection
X100
Connection type
pluggable screw terminal
Min. cable cross-section mm² 1
Max. cable cross-section
mm²
2.5
Stripping length
mm
8
Tightening torque
Nm
0.5
Required tool
0.5 x 3.0
Connection PE
Connection type
PE screw
Min. cable cross-section
mm²
1
Max. cable cross-section
mm²
6
Stripping length
mm
10
Tightening torque Nm 1.2
Required tool
0.8 x 5.5
Mains connection
Inverter
VS30-40-7P3 VS30-40-9P5 VS30-40-013 VS30-40-016
Connection
X100
Connection type
Screw terminal
Min. cable cross-section
mm²
1.5
Max. cable cross-section
mm²
6
16
Stripping length mm 9 11
Tightening torque
Nm
0.5
1.2
Required tool
0.6 x 3.5
0.8 x 4.0
Connection PE
Connection type
PE-screw
Min. cable cross-section
mm²
1.5
Max. cable cross-section
mm²
6
16
Stripping length
mm
10
11
Tightening torque
Nm
1.2
3.4
Required tool
0.8 x 5.5
PZ2
